Payment & Shipping Terms:
|Place Of Origin:||Shenzhen, China||Tube Chip Color:||Full Color|
|Physical Density :||65536 Dots/㎡||LED Chip:||1921|
|Cabinet Size :||W500m×H500mm; W500m×H1000mm||Lifespan:||>100000 Hours|
led panel outdoor,
hd led screen
high contrast P3.91 SMD1921 outdoor video wall led display screen
1. LED lamps failure rate <0.0001;
we select super led tips with high brightness, broad viewing angle(H140degree, V140degree), all the LEDs are ageing for 72 hours before assembly;
2. Modules: we have 11 years for manufacturing led screens, both price and quality advantages;
We use 1R1G1B pixel configuration to realise high brightness.Modules would be aging for 72 hours, after assembly into a screen, still aging 72 hours. so the final LEDs are aging at least for 216 hours, up to 9 days.
3. Cabinets: Aluminum/ Iron, quick to assemble and disassemble and waterprrof well.
4. Screen: use state-of-the-art LED drive IC-MBI5026/MBI5124, brightness can up to 8000cd/m2, live color video and vivid image with 256 grey level.
For outdoor led displays, all of them are IP 65 and designed to withstand harsh environmental conditions, such as sun glare, heat, cold, and humidity. You can see more details in the quotation.
5.Packing: Anti-shaking wooden case, which is lighter than normal wooden case but more protective to the goods. Flight case with wheel which is more convenient .
6. Spare parts for free: Our screen's scotoma rate is below 0.0002, but to prevent accidental, we provide some free spare parts according to the size of screen.
7. Warranty for 24 months: During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution according to situations.
8. Technology support: we have full hardware and software files available for all you need, we are always here to service on you.
|Optimal Viewing Distance||>4m||>4m|
|Pixel Density(Pixel /m2)||65536||43264|
|Driving Method||1/16 Scan||1/13 Scan|
|View angle / °||140H,120V||140H,120V|
|Luminance of white balance||≥6500 CD/m^2||≥6500 CD/m^2|
|Weight of cabinet/kg||10||9|
|Working Voltage||AC 220V/110V±10%|
|Operating Temperature||below 30 to above 50|
|Grey scale/color||displaying colors≥16.7M(synchronized)|
256 levels of each color(manually),
100 levels of each color(automatically)
|Input signal||RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc|
|Control system||linsn/Novastar(sending card,receiving cards and Hubs)|
|Average of non-failure life||>50,00h|
|Defect dot rate||<0.0001|
Famous Brands Raw Material Selection
1) LED: well-known international brand,with wide viewing angle ,little attenuation ,good heat dissipation, and vivid colors.
2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba, avoidable the defective
phenomena, such as dark bright, virtual light and so on.
3) Power supply: industrial-strength brand.The power maximum power resere of 20% the space , the range of voltage fluctuation is less 5%, high stability.
4) Connector: Aerial grade brands ensure the stable transmission of power and signal.
5) PCB Board: adopt 4-layer design.
6) Easy installation:100 pieces of cabinets' installation can be finished in one hour by one person.
The replacement of any cabinet can be done within 50 seconds.
1) Reply your inquiry in 24 working hours.
2) Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3) Customized design is available,OEM & ODM are welcomed.
4) Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5) Special discount and protection of sales area provided to our distributor.
6) Warmly welcome your visit in our company if available.
7) Warranty: 24 months
Packaging & Shipping
6 panels or 8 panels in 1 flight case
Contact Person: Candy Xu
