High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB

High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB

  • High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB
  • High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB
  • High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB
  • High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB
High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB
Product Details:
Place of Origin: China(mainland)
Brand Name: Kailite
Certification: CE,FCC,ROHS
Model Number: P3.91
Payment & Shipping Terms:
Minimum Order Quantity: 1 suqare meter
Price: Negotiation
Packaging Details: wooden case/ flight case packing
Delivery Time: 5--20 working days
Payment Terms: T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability: 8000sqm per month
Contact Now
Detailed Product Description
Place Of Origin: Shenzhen, China Tube Chip Color: Full Color
Pixel Pitch: 3.91mm Brightness: >6500nits
Physical Density : 65536 Dots/㎡ LED Chip: 1921
Cabinet Size : W500m×H500mm; W500m×H1000mm Lifespan: >100000 Hours
High Light:

led panel outdoor

,

hd led screen

High Contrast football field front maintain SMD2121 P3.91 RGB outdoor Rental LED Screen 1920hz





Product advantage:


1. LED lamps failure rate <0.0001;

we select super led tips with high brightness, broad viewing angle(H140degree, V140degree), all the LEDs are ageing for 72 hours before assembly;

2. Modules: we have 11 years for manufacturing led screens, both price and quality advantages;

We use 1R1G1B pixel configuration to realise high brightness.Modules would be aging for 72 hours, after assembly into a screen, still aging 72 hours. so the final LEDs are aging at least for 216 hours, up to 9 days.

3. Cabinets: Aluminum/ Iron, quick to assemble and disassemble and waterprrof well.

4. Screen: use state-of-the-art LED drive IC-MBI5026/MBI5124, brightness can up to 8000cd/m2, live color video and vivid image with 256 grey level.
For outdoor led displays, all of them are IP 65 and designed to withstand harsh environmental conditions, such as sun glare, heat, cold, and humidity. You can see more details in the quotation.

5.Packing: Anti-shaking wooden case, which is lighter than normal wooden case but more protective to the goods. Flight case with wheel which is more convenient .

6. Spare parts for free: Our screen's scotoma rate is below 0.0002, but to prevent accidental, we provide some free spare parts according to the size of screen.

7. Warranty for 24 months: During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution according to situations.

8. Technology support: we have full hardware and software files available for all you need, we are always here to service on you.







Specification:



Items Parameter
Pixel Pitch P3.91mm P4.81mm
Module Resolution(W*H) 128*128 104*104
Pixel Configuration 1R1G1B 1R1G1B
Optimal Viewing Distance >4m >4m
Pixel Density(Pixel /m2) 65536 43264
Driving Method 1/16 Scan 1/13 Scan
View angle / ° 140H,120V 140H,120V
Module size(mm) 250x250 250x250
Cabinet size(mm) 500x500/500x1000 500x500
Luminance of white balance ≥6500 CD/m^2 6500 CD/m^2
LED Encapsulation SMD1921 SMD1921
Weight of cabinet/kg 10 9
Working Voltage AC 220V/110V±10%
Operating Temperature below 30 to above 50
Grey scale/color displaying colors≥16.7M(synchronized)
Brightness adjustment

256 levels of each color(manually),

100 levels of each color(automatically)

Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system linsn/Novastar(sending card,receiving cards and Hubs)
Average of non-failure life

>50,00h

Life span >100,000h
Defect dot rate <0.0001







Famous Brands Raw Material Selection:



1) LED: well-known international brand,with wide viewing angle ,little attenuation ,good heat dissipation, and vivid colors.



2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba, avoidable the defective

phenomena, such as dark bright, virtual light and so on.



3) Power supply: industrial-strength brand.The power maximum power resere of 20% the space , the range of voltage fluctuation is less 5%, high stability.



4) Connector: Aerial grade brands ensure the stable transmission of power and signal.



5) PCB Board: adopt 4-layer design.



6) Easy installation:100 pieces of cabinets' installation can be finished in one hour by one person.

The replacement of any cabinet can be done within 50 seconds.



Services:



1) Reply your inquiry in 24 working hours.

2) Experienced staffs answer all your query in fluent English,Spanish,French,German etc

3) Customized design is available,OEM & ODM are welcomed.

4) Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.

5) Special discount and protection of sales area provided to our distributor.

6) Warmly welcome your visit in our company if available.

7) Warranty: 24 months





Packaging & Shipping:



6 panels or 8 panels in 1 flight case or the wooden case.



High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB 0







High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB 1



High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB 2



High Contrast Outdoor Led Video Wall Football Field Front Maintain SMD2121 P3.91 RGB 3
