High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS

High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS

  • High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS
  • High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS
  • High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS
High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS
Product Details:
Place of Origin: Guangdong,China
Brand Name: Kailite
Certification: CE FCC ROHS
Model Number: P6 outdoor
Payment & Shipping Terms:
Minimum Order Quantity: 5SQM
Price: Negotiation
Packaging Details: Flight package and wood package
Delivery Time: ahout 20 days
Payment Terms: L/C, T/T
Supply Ability: 1500SQM/per mouth
Contact Now
Detailed Product Description
Use Environment: Outdoor Pixel Pitch: 6mm
Module Size: 192*192mm Physical Density : 27777dots/㎡
Pixel Configuration : 1R1G1B LED Chip: SMD3535
Module Resolution: 32*32 Module Power: 35w
Recommended Viewing Distance: 6-70m Best Viewing Angle : H: 120°; V:120°
Maximum Power Consumption: 900w Average Power Consumption: 480w
High Light:

smd led panel

,

led display smd

P6 Outdoor LED Video Screens, 6mm led display Full-color real pixels video



Description:



1. personalized and complete solution for your case
2. factory price and good quality
3. convenient and fast installation ,easy maintenance
4. 2 years wanrranty



Competitive advantages:



1. We are led screen manufacturer for many years, quality is guaranteed.
2. Because we are factory, our price is 5%-10% lower than middleman and trafficker at same level.
3. Professional sales and technical team of 15 people to ensure perfect results.
4. Customer requirements are fundamental, we make different solutions accroding different requirements of customers.



Item PH6
Use environment Outdoor
Pixel pitch 6mm
Module size 192*192mm
Physical density 27777dots/㎡
Pixel configuration 1R1G1B
LED chip SMD3535
Module resolution 32*32
Module power 35w
Recommended viewing distance 6-70m
Best viewing angle H: 120°; V:120°
Maximum power consumption 900w
Average power consumption 480w
Cabinet size 576*576mm
Standard cabinet resolution 96*96
Driving method 1/8 Scan, Constant Current
Video frame rate ≥60 Hz
Rate refresh ≥1200Hz
White balance brightness ≥6500cd
Operating temperature/Humidity -30℃~+45℃
Ingress protection Front:IP 67; Back:IP65
Input voltage 110-220V AC±10%
Gray scale /Color Display Colors ≥16.7N(Synchronize)
Brightness control Manual/Automatic
Input signal RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Control system PCTV+DVI video card+control card+fiber
MBTF >5000 hours
Life time >100,000 Hours
The rate <0.0002



High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS 0

High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS 1

High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS 2

High Refresh Video Wall Displays P6 Led Screen With 16.7N Grey Scale ROHS 3



After-sale service

We promise we provide 2 years warranty for free maintain for our products and full life tracking service.

1. During the warranty period, we will repair the equipment free of charge unconditionally if the problem is caused by product quality or production and installation problem.

2. When the warranty expires. we continue to provide maintenance service for whole life of the equipment with relative service/material cost paid.
