P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size

P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size

  • P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size
  • P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size
  • P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size
  • P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size
  • P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size
  • P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size
P10 P8 Outdoor Full Color Led Display Advertising Video SMD 320 * 160mm Size
Product Details:
Place of Origin: China (Mainland)
Brand Name: KAILITE
Certification: CE, FCC, ROHS
Model Number: P10
Payment & Shipping Terms:
Minimum Order Quantity: 1 Square meters
Price: Negotiation
Packaging Details: wooden packing; flight case packing
Delivery Time: 7-21 work days
Payment Terms: T/T, D/A, D/P, L/C
Supply Ability: 8000 square meters per month
Contact Now
Detailed Product Description
Pixel Pitch: 10mm Function: Video
Physical Density: 10000dots/㎡ Led Chip: SMD3535
Brightness: ≥5500cd Ingress Protection: Front: IP67; Back: IP65
Warranty: 2 Years Life Time: > 100, 000 Hours
High Light:

outdoor screen panels

,

outdoor led screen

,

SMD3535 P8 led display screen



Outdoor SMD full color 320 * 160 mm P10 P8 led display screen





Applications:



------ Trading, financial information display



------ Airport flight information display



------ Stadium Information Display



------ Road traffic information display



------ Performances and gatherings



------ Exhibition and rental





Specifications:



1.p10 outdoor led display



2.Factory price and good quality



3.Environmental-friendly and energy-saving.



4.Convenient and easy maintenance


5.Good heat dissipation capability because of the unique design of vent fan.



composition diagram

p10 led display outdoor.jpg

p10 led module .jpg

p10 led display outdoor cabinet.jpg

Inside structure.jpg

p10 led display outdoor testing.jpg



What is the details of our p10 p8 outdoor led display





Pixel Pitch 8mm 10mm
Color full color full color
Use environment outdoor outdoor
pixel pitch 8mm 10mm
Module size 256*128mm 320*320mm
physical density 15625 dots/square meter 10000dots/square meter
Pixel configuration 1R1G1B 1R1G1B
LED chip SMD3535 SMD3535
Module resolution 32*16 32*32
Module power 30w 70w
Recommended viewing distance 8-70m 10-100m
Best viewing angle H: 120°; V:120° H: 120°; V:120°
Maximum power consumption 850w 620w
Average power consumption 420w 250w
Cabinet size 768*768mm 960*960mm
Standard cabinet resolution 96*96 96*96
Standard cabinet Weight 42kg/panel 50kg/panel
Driving method 1/4 Scan, Constant Current 1/4 Scan, Constant Current
Video frame rate ≥60 Hz ≥60 Hz
Rate refresh ≥1200Hz ≥1200Hz
White balance brightness ≥6500cd ≥7500cd
Operating temperature/Humidity -30℃~+45℃ -30℃~+45℃
Ingress protection Front:IP 67; Back:IP65 Front:IP 67; Back:IP65
Input voltage 110-220V AC±10% 110-220V AC±10%
Gray scale /Color Display Colors ≥16.7N(Synchronize) Display Colors ≥16.7N(Synchronize)
Brightness control Manual/Automatic Manual/Automatic
Input signal RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Control system PCTV+DVI video card+control card+fiber PCTV+DVI video card+control card+fiber
MBTF >500 hours >500 hours
Life time >100,000 Hours >100,000 Hours
The rate <0.0001 <0.0001



Four main reasons why our customer choose us



1. We are led display manufacturer for 10 years, quality is guaranteed



2. Because we are factory, our price is 5%-10% lower than middleman and trafficker at same level



3. Professional sales and technical team of 15 people to ensure perfect results



4. Customer requirements are fundamental, we make different solutions accroding different requirements of customers



We are confident our products and sevice will satisfy you!

Trust us! we won't let you down
