P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel

P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel

P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel
P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel
P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel
Product Details:
Place of Origin: Shenzhen, China
Brand Name: KAILITE
Certification: IOS9001 , IOS2000,FCC,RoHS,CE,CCC
Model Number: P2.5 P3 P4 P5
Payment & Shipping Terms:
Minimum Order Quantity: 2 square meters
Price: Negotiatable
Packaging Details: carton/ wooden case/fight case
Delivery Time: about 22 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 9000 square meters per month
Contact Now
Detailed Product Description
Warranty: 2 Years Brightness: >800nits
Module Size: 320x160mm/240*120mm Application: Indoor
Life Span: 100000 Hours Color: 1R1G1B
Led Type: SMD2020 Refresh Rate: 1920Hz-3840Hz
High Light:

320*160mm Indoor Flexible Led Screen

,

800nits Flexible Led Screen

,

320*160mm Curved Led Panel

P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel



Indoor Flexible Video Led Screen P2.5 320*160mm HD Soft Curved Led Panel



Description of soft led screen

The LED flexible screen can be bent, rotated, folded, It can unaffected by the shape of buildings.It can also present more delicate aolors. Using high-density SMD LED technology, which has the advantages of high brightness, high contrast, high resolution, low energy consumption, long life, good waterproof, shockproof and compression resistance.



Specifications of soft led module

Item P2.5 P3 P4 P5
Pixel pitch 2.5mm 3mm 4mm 5mm
Module size 320*160mm 240*120mm 320*160mm 320*160mm
Module size 128*64 80*40 80*40 64*32
Physical density 160000 dots/㎡ 111111 dots/㎡ 62500 dots/㎡ 40000 dots/㎡
LED type SMD2020 SMD2020 SMD2020 SMD2020
Module power 18w 18w 18w 18w
Best viewing distance ≥2.5m ≥3m ≥4m ≥5m
Best viewing angle H: 160°; V:160° H: 160°; V:160° H: 160°; V:160° H: 160°; V:160°
Driving method (Constant Current) 1/32 Scan 1/20 Scan 1/20 Scan 1/16 Scan
Video frame rate ≥60 Hz ≥60 Hz ≥60 Hz ≥60 Hz
Refresh rate 1920-3840Hz 1920-3840Hz 1920-3840Hz 1920-3840Hz
Brightness ≥800nits ≥800nits ≥800nits ≥800nits
Grey Level 12-16bit 12-16bit 12-16bit 12-16bit
Ingress protection IP43 IP43 IP43 IP43
Life Time >100,000 Hours >100,000 Hours >100,000 Hours >100,000 Hours
The rate <0.0002 <0.0002 <0.0002 <0.0002





Features of soft led screen

1. Excellent flexible. It can be suitable different shape.



2. Lower consumption +noiseless



3. easy and fast installation



4. Designed by front maintenance. Easy maintenance.





P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel 0

P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel 1P2.5 320*160mm Indoor Flexible Led Screen HD Soft Curved Led Panel 2





Application of soft led screen

It can be widely used in indoor and outdoor occasions.such as exhibitions, concerts, speeches, advertisements, sports events, etc., and has achieved good visual effects and advertising effects.





Why choose KAILITE?

1. We are a leading manufacturer specialized in led screeen industry more than 14 years.



2.we insist quality frist.We will conduct product inspection before,during,after production.



3.Quickly response.we are online 24 hours,welcome to consult.



4.We are factory so that we can provide factory direct price for you.





After-sell Service:
1) 2 years warranty for all parts



2) Free instructure giude will be send to you.

3) We can provide remote service for you.

4) we will reponse you anytime in 7*24 houres if you have any question about the led screen,

6) Free technical training for how to use and handle the software.





FAQ:

1. Are you a trade company or a factory?
A:we are a factory.



2. How long is the warranty?
A:2 years.



3: This is my first time buy led screen, do you have a instructional video?

Yes, we have. this service is free.



4. Do you support customized?

Yes sure. Our products can be customized according to your requirement.
