| Place of Origin: | Shenzhen, China |
| Brand Name: | KAILITE |
| Certification: | IOS9001 , IOS2000,FCC,RoHS,CE,CCC |
| Model Number: | P4,P5, P8, P10 |
| Minimum Order Quantity: | 2 square meters |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Wooden case for outdoor advertising led screen |
| Delivery Time: | 22-24 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 8000 square meters per month |
| Display Function: | Outdoor Advertising, Billboard, Exhibition | Brightness: | 6000cd/sqm |
|---|---|---|---|
| Warranty: | 2-3 Years | The Rate: | <0.0002 |
| Module Size: | 320mm*160mm | Led Chip: | SMD3535 |
| Name: | P8 P10 HD 960*960 Cabinet Led Display Board | Cabinet Material: | Iron |
| High Light: | SMD3535 Outdoor Full Color Led Display,SMD3535 Full Color Led Signs,960*960mm Cabinet LED Display Board |
||
P8 P10 HD SMD3535 Outdoor Full Color Led Display 960*960mm Cabinet
Full Color Led Signs Outdoor P8 P10 HD 960*960 Cabinet Led Display board
Quick Details of 960*960mm Outdoor LED Display
1) With characteristic of waterproof,moistureproof and dustproof.
2) With 6500cd high brightness, could be seen clearly even with strong sunshine.
3) High temperature and low temperature resistance,Led billboard could be working in -30℃~60℃.
4) More durable as we adopt the high quality and high temperature resistance materials, such as power supply, cables, power lines etc.
Specifications of 960*960mm series of outdoor led screens
| Item | P8 | P10 |
| Pixel pitch | 8mm | 10mm |
| Module size | 320*160mm | 320*160mm |
| Module resolution | 40×20 | 32×16 |
| Physical density | 15625 dots/㎡ | 10000 dots/㎡ |
| LED type | SMD3535 | SMD3535 |
| Cabinet size | 960×960×mm | 960×960×mm |
| Cabinet resolution | 120×120 | 96×96 |
| Cabinet material | Die casting aluminum | Die casting aluminum |
| Maintenance way | Rear | Rear |
| Best viewing distance | ≥8m | ≥10m |
| Best viewing angle | H: 140°; V:140° | H: 140°; V:140° |
| Driving method (Constant Current) | 1/5 Scan, | 1/2 Scan |
| Video frame rate | ≥60 Hz | ≥60 Hz |
| Refresh rate | 1920-3840Hz | 1920-3840Hz |
| Brightness | ≥6000nits | ≥6000nits |
| Grey Level | 12-16bit | 12-16bit |
| Ingress protection | IP65 | IP65 |
| Life Time | >100,000 Hours | >100,000 Hours |
| The rate | <0.0002 | <0.0002 |
Features of 960*960mm series outdoor led display
1) adopt rear maintenance, fast and convienient maintenance.
2) high contast, can present more vivid images and videos.
3) Led screen could be working in -30℃~60℃
4) Support display almost all format of video and images.
Application of 960*960mm series outdoor led screen
Mainly used in outdoor advertising media, government and enterprise engineering, cultural tourism, sports venues, image publicity, commercial real estate and other fields.
Why choose KAILITE?
1. We have rich experience in led screen industry more than fourteen years.
2. Innovative on quality inspection with "Dual chekcking mode", QC first, sales person check repeatly, Quality is well guaranteed.
3. We are factory, we have strong productivity, more than 9000 sqm every month.
4. More professional. We have 14 years experience, we can give you more professional advice.
Our Service:
1) A two-year warranty
2) providing free frame structure drawing, as well as power and data cables wiring diagram. easy for your to set up the led screen .
3) Free remote control debuggine serice if you need
4) We can design special product for you.
FAQ:
1. I want to have an sample, can you provide?
A:Sure, we will provide your an sample according to your requirement.
2. Where is your factory?
A: Our factory in Shenzhen
3: Can you provide installation guide services for me?
yes, sure! we are very glad to help you.
4. Do you support customized?
Yes.we support OEM/ODM services.
