High Resolution Seamless Splicing Indoor LED Video Wall Panel Office

High Resolution Seamless Splicing Indoor LED Video Wall Panel Office

High Resolution Seamless Splicing Indoor LED Video Wall Panel Office
High Resolution Seamless Splicing Indoor LED Video Wall Panel Office
High Resolution Seamless Splicing Indoor LED Video Wall Panel Office
Product Details:
Place of Origin: Shenzhen China
Brand Name: KAILITE
Certification: CE RoHS ISO9001 UL FCC CCC
Model Number: P3.07
Payment & Shipping Terms:
Minimum Order Quantity: 2 square meters
Price: Negotiation
Packaging Details: Wooden case/Flight case
Delivery Time: About 22-24 days
Payment Terms: T/T, L/C, D/A, D/P, MoneyGram, Western Union
Supply Ability: 8000 square meters per month
Contact Now
Detailed Product Description
Product Name: P3.07 Indoor LED Video Wall Panel Pixel Pitch: 3.076mm
Cabinet Size: 640*480mm Defective Rate: <0.0002
Input Voltage: AC 110-220v ±10% Life Time: Over 100000 Hours
High Light:

Seamless Splicing Indoor LED Video Wall

,

3.076mm Indoor LED Video Wall

,

Seamless Splicing Indoor Led Screen Wall

High Resolution Seamless Splicing Indoor LED Video Wall Panel Office



Description of Indoor LED Video Wall Panel



Indoor LED Video Wall Panel pixel include 2mm, 2.5mm, 3.07mm, 4mm, within these pixels, 2.5mm, 3.07mm, are the most hot-selling and highest cost-effective series. You can use it in office for conference display or fixed in shopping mall for advertising.


Product Specification:


Item KP2 KP2.5 KP3.07 KP4
Pixel pitch 2mm 2.5mm 3.076mm 4mm
Module size 320*160mm 320*160mm 320*160mm 320*160mm
Module resolution 160×80 128×64 104×52 80×40
Physical density 250000 dots/㎡ 160000 dots/㎡ 105688 dots/㎡ 62500 dots/㎡
LED type SMD1515 SMD2020 SMD2020 SMD2020
Cabinet size 640*480mm 640*480mm 640*480mm 640*480mm
Cabinet resolution 320*240 256*192 208*156 160*120
Maintenance way Front Front Front Front
Best viewing distance ≥2.5m ≥2.9m ≥3m ≥3m
Best viewing angle H: 160°; V:160° H: 160°; V:160° H: 160°; V:160° H: 160°; V:160°
Driving method (Constant Current) 1/40 Scan 1/32 Scan 1/26 Scan, 1/20 Scan
Video frame rate ≥60 Hz ≥60 Hz ≥60 Hz ≥60 Hz
Refresh rate 1920-3840Hz 1920-3840Hz 1920-3840Hz 1920-3840Hz
Brightness ≥800nits ≥800nits ≥800nits ≥800nits
Grey Level 12-16bit 12-16bit 12-16bit 12-16bit
Ingress protection IP43 IP43 IP43 IP43
Life Time >100,000 Hours >100,000 Hours >100,000 Hours >100,000 Hours
The rate <0.0002 <0.0002 <0.0002 <0.0002



High Resolution Seamless Splicing Indoor LED Video Wall Panel Office 0





Features of products:


1. Front maintenance design, save space for maintenance.


2. High refresh rate and high resolution, better visual effects.


3. Customized size, adjustable proposal.


4. Seamless Splicing, the picture is coherent.


5. Worry-free Service (Save your time and easy of your mind) from experienced engineers and sales team.





Shipping and Package



The main shipping way is by sea and air, conbined with road transport. we have different choices for package, including Wooden case (most time for fixed series), flight case and cartoon.



High Resolution Seamless Splicing Indoor LED Video Wall Panel Office 1

High Resolution Seamless Splicing Indoor LED Video Wall Panel Office 2



After-sell service:


1. 24-hour hotline service, including counseling and technical guidance.


2. Installation guidance by professional and experienced engineers and staff.


3. Failure maintenance of LED panels.


4. Free professional technical training.


5. Warranty service.



FAQ:


1. Do I need to buy other equipment to install LED screen?
You just need to prepare structure and installation tools.


2.Could I get a sample before place mass order?
Yes of course, sample is available for your test.


3. What is LED screen common size?
16:9 and 4:3 aspect ratio is popular.


4. Is it okay to print my logo on your product?
Yes, and we provide free printing service.


5. What is your terms of payment?
T/T 40% as deposit, and 60% before delivery. We'll show you the photos of the products and packages before you pay the balance.
