1R1G1B Indoor outdoor advertising led display screen Rental for Virtual Events Trade Show

1R1G1B Indoor outdoor advertising led display screen Rental for Virtual Events Trade Show

  • 1R1G1B Indoor outdoor advertising led display screen Rental for Virtual Events Trade Show
  • 1R1G1B Indoor outdoor advertising led display screen Rental for Virtual Events Trade Show
1R1G1B Indoor outdoor advertising led display screen Rental for Virtual Events Trade Show
Product Details:
Place of Origin: Shenzhen, China(mainland)
Brand Name: OEM/ODM
Certification: CE,FCC,ROHS ISO9001
Model Number: P3.91
Payment & Shipping Terms:
Minimum Order Quantity: 2 suqare meter
Price: Negotiation
Packaging Details: wooden case/ flight case packing
Payment Terms: T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability: 8000sqm per month
Contact Now
Detailed Product Description
Pixels: 3.91mm LED Specification: SMD 2121
Module Size: 250*250mm Pixel Configuration: 1R1G1B
Driving Method: 1/16 Scan Module Pixel Density: 65536 Dots/㎡
Packaging Details: Flight Case Delivery Detail: Shipped In 15 Days After Payment
High Light:

outdoor advertising led display screen

,

outdoor led video display

1R1G1B Indoor outdoor advertising led display screen Rental for Virtual Events Trade Show



Product Description





1.Ultrathin and light weight: Each cabinet weighs only 7 kgs, easy to install and transport.



2.Noiseless: Die-casting Aluminum cabinets, fanless design with noiseless power supply.



3.Seamless: High precision up to 0.1mm.



4.Fast Installation and dismantling: connection lock between cabinets are patented, closely combined, safe, reliable and adjustable, 50 cabinets can be installed in one hour.



5.Front Service: Use patented spring bead positioning pin and connection lock, any defective cabinet can be removed easily without dismantling the whole screen.



6.Mask without screws: mask fixation uses patented snap Joints instead of screws, it takes only 25 seconds to assemble one module, much more convenient for maintenance.



7.Unique blanking circuit: high definition display by eliminating the row / line after-image without damaging the LED lamps.



8.Energy saving: low electric current, high-bright lamps, save 30% electricity.



9.High refresh rate, high gray level:  using MBI driving IC, refresh rate is more than 4000HZ, the gray level is still high even under the condition of low brightness.



10.Color correction: support dot-to-dot correction, guarantee the consistence of LED color and brightness, No chromatic aberration for new screens.



11.Dual back-up: both power supply and system dual back-up are optional, reliable performance.




Technical Parameters of Indoor P3.91 Die-casting Aluminum LED Display
Pixel Pitch
3.91 mm
Pixel Density
65536 dots/㎡
Brightness
≥1500 cd/㎡
Viewing Angle
H:140°, V:120°
LED Specification
SMD 2121
Pixel Configuration
1R1G1B
Module and Cabinet Size
250mm(W)*250mm(H)
500mm(W)*1000mm(H)
Resolution
64*64 dots
Weight
7kg/cabinet
Best Viewing Distance
3.91m-100m
Driving Method
1/16 scan
Refresh Rate
≥2000HZ
Gray/Color
65536 Gray, Color 1 billion
Control System
Synchronous/off-line control system, fiber transmisson
Working Voltage
AC 220V/110V, 50/60 HZ
Temperature Range
Storage: -20ºC ~ 65ºC; Working: -20ºC ~ 50ºC
Max. Power Consumption
200 W/PC
Life-span
>100,000hrs
MTBF
>5,000hrs
Dead Dot Rate
<0.0001
LED Parametr
R: (625-630nm) G: (522.5-525nm) B: (467.5-470nm)
Control Method
Main Controller +Synchronous +DVI Display Card
Relative Humidity
≤95%



Product Application



Applied to place where it requires high-definition display and fast installation such as Outdoor stage, television studio, concert, exhibition, etc.




After-sales Service


We promise to provide 2 years warranty for free maintain for our products and full life tracking service.


1. During the warranty period, we will repair the equipment free of charge unconditionally if the problem is caused by product quality or production and installation problem.


2. If the warranty expires, we continue to provide lifetime maintenance service of the equipment with relative service or material fee-based.

3. Free updating software service.

4. Quick respond, fast repair and and instant help promised by sending technicians to help test and repair on site within 36 hours after customer’s request.


5. We usually finish repairing within 5 days after receiving the defective equipment.







Packing, Shipping and Payment

Payment Terms
30% deposit before production, 70% balance before shipping
---T/T, L/C & Western Union
Packing
Flight case
Shipping
10-15 working days upon receiving deposit payment
