Place of Origin: | Shenzhen, China(mainland) |
Brand Name: | OEM/ODM |
Certification: | CE,FCC,ROHS ISO9001 |
Model Number: | P3.91 |
Minimum Order Quantity: | 2 suqare meter |
---|---|
Price: | Negotiation |
Packaging Details: | wooden case/ flight case packing |
Payment Terms: | T/T, D/A, D/P, L/C, Western Union, MoneyGram |
Supply Ability: | 8000sqm per month |
Pixels: | 3.91mm | LED Specification: | SMD 2121 |
---|---|---|---|
Module Size: | 250*250mm | Pixel Configuration: | 1R1G1B |
Driving Method: | 1/16 Scan | Module Pixel Density: | 65536 Dots/㎡ |
Packaging Details: | Flight Case | Delivery Detail: | Shipped In 15 Days After Payment |
Highlight: | outdoor advertising led display screen,outdoor led video display |
1R1G1B Indoor outdoor advertising led display screen Rental for Virtual Events Trade Show
1.Ultrathin and light weight: Each cabinet weighs only 7 kgs, easy to install and transport.
2.Noiseless: Die-casting Aluminum cabinets, fanless design with noiseless power supply.
3.Seamless: High precision up to 0.1mm.
4.Fast Installation and dismantling: connection lock between cabinets are patented, closely combined, safe, reliable and adjustable, 50 cabinets can be installed in one hour.
5.Front Service: Use patented spring bead positioning pin and connection lock, any defective cabinet can be removed easily without dismantling the whole screen.
6.Mask without screws: mask fixation uses patented snap Joints instead of screws, it takes only 25 seconds to assemble one module, much more convenient for maintenance.
7.Unique blanking circuit: high definition display by eliminating the row / line after-image without damaging the LED lamps.
8.Energy saving: low electric current, high-bright lamps, save 30% electricity.
9.High refresh rate, high gray level: using MBI driving IC, refresh rate is more than 4000HZ, the gray level is still high even under the condition of low brightness.
10.Color correction: support dot-to-dot correction, guarantee the consistence of LED color and brightness, No chromatic aberration for new screens.
11.Dual back-up: both power supply and system dual back-up are optional, reliable performance.
Technical Parameters of Indoor P3.91 Die-casting Aluminum LED Display | |||
Pixel Pitch
|
3.91 mm
|
Pixel Density
|
65536 dots/㎡
|
Brightness
|
≥1500 cd/㎡
|
Viewing Angle
|
H:140°, V:120°
|
LED Specification
|
SMD 2121
|
Pixel Configuration
|
1R1G1B
|
Module and Cabinet Size
|
250mm(W)*250mm(H)
500mm(W)*1000mm(H)
|
Resolution
|
64*64 dots
|
Weight
|
7kg/cabinet
|
Best Viewing Distance
|
3.91m-100m
|
Driving Method
|
1/16 scan
|
Refresh Rate
|
≥2000HZ
|
Gray/Color
|
65536 Gray, Color 1 billion
|
Control System
|
Synchronous/off-line control system, fiber transmisson
|
Working Voltage
|
AC 220V/110V, 50/60 HZ
|
Temperature Range
|
Storage: -20ºC ~ 65ºC; Working: -20ºC ~ 50ºC
|
Max. Power Consumption
|
200 W/PC
|
Life-span
|
>100,000hrs
|
MTBF
|
>5,000hrs
|
Dead Dot Rate
|
<0.0001
|
LED Parametr
|
R: (625-630nm) G: (522.5-525nm) B: (467.5-470nm)
|
||
Control Method
|
Main Controller +Synchronous +DVI Display Card
|
Relative Humidity
|
≤95%
|
Applied to place where it requires high-definition display and fast installation such as Outdoor stage, television studio, concert, exhibition, etc.
We promise to provide 2 years warranty for free maintain for our products and full life tracking service.
1. During the warranty period, we will repair the equipment free of charge unconditionally if the problem is caused by product quality or production and installation problem.
2. If the warranty expires, we continue to provide lifetime maintenance service of the equipment with relative service or material fee-based.
3. Free updating software service.
4. Quick respond, fast repair and and instant help promised by sending technicians to help test and repair on site within 36 hours after customer’s request.
5. We usually finish repairing within 5 days after receiving the defective equipment.
Packing, Shipping and Payment |
|||
Payment Terms
|
30% deposit before production, 70% balance before shipping
---T/T, L/C & Western Union
|
||
Packing
|
Flight case
|
||
Shipping
|
10-15 working days upon receiving deposit payment
|
