Place of Origin: | china |
Brand Name: | kailite |
Certification: | ccc ce rohs fcc... |
Model Number: | p3.91 |
Minimum Order Quantity: | 10 Square Meter |
---|---|
Price: | US $550-999 / Square Meter |
Packaging Details: | woodenbox |
Delivery Time: | 15~20work days |
Supply Ability: | 10000Square Meter /month |
Module Size: | 250 X 250mm | Pixel Pitch: | 3.91mm |
---|---|---|---|
Pixel Configuration: | 1R1G1B | Package Mode: | SMD2727 |
Brightness Of White Balance: | ≥6,500cd/sqm | Dimension: | 500 X 500mm Or 500 X 1000mm (12.0KG/PC) |
Power Supply: | 5V 60A X 1 Or 2pcs | Operation Humidity: | 10% - 95% |
Weight: | 0.155kg | Scan Mode: | 1/ 13 Scan |
Highlight: | OEM P4.81 Outdoor Rental Led Screen,1R1G1B outdoor led screen hire,1R1G1B Outdoor Rental Led Screen |
OEM P4.81 Outdoor Rental Led Screen With 1R1G1B Pixel Configuration
Aluminum die casting waterproof cabinet outdoor digital led display for rental
Supporting OEM service, According your willings to design and make what you need
2 years warranty for our products and life time maintance for all parts
Specifications:
led module parameter | ||
Technical parameters | UNIT | parameters Values |
Pixel pitch | mm | 4.81 |
module size | mm | 250*250 |
Physical density | dots/㎡ | 65536 |
Pixel configuration | RGB | 1,1,1 |
Driving method | Constant current 1/13scan | |
Led lamp | Smd | 3528 |
module resolution | dots | 52*52 |
Module weight | Kg | 0.32 |
Ingress protection | IP43 | |
Module consumption | W | 25 |
led display parameter | ||
Viewing angle | Deg. | H120 V120 |
Viewing distance | m | 5-35 |
Maximum power | W/㎡ | 780w |
Frame Frequency | Hz | ≥60 |
Refresh frequency | Hz | ≥1200 |
Equilibrium brightness | cd/㎡ | ≥1500 |
Working environment temperature | 0C | -30~60 |
Display working voltage | VAC | 220V±15%/110V±15% |
Gray scale/color | ≥16.7M color | |
Input signal | RF S-Video RGB etc | |
Control system | Nova/Linsn control system | |
Mean free error time | hours | >5000 |
life time | hours | >100,000 |
Lamp failure frequency | <0.0001 |
Features:
1. Light weight: The aluminum die-casting technology we adopt is about 7.5kg which is convenient for assembly and disassembly
2. Hight refresh rate: Over 1200 Hz refresh rate to ensure the picture wrinkle-less,line-less and stable.
3. Low brightness and High gray scale:14Bit-16Bit gray scale to bring excellent performance when
brightness is reduced to 25%.
4. Easy to install: Don't need to worry about the installation, it is easy, because of the design of the Die casting cabinet, Just like building block
5. High IP: The IP65 insures the reliable operation in different enrionment, and it is more safe
6. Low brightness and Hight gray scale:14Bit-16Bit gray scale to bring perfect display performance with no shadows
advantages:
1. 7 Years led display factory, We are led screen manufacturer for 7 years, we have rich experience in outdoor and indoor led display, quality is guaranteed
2. Up to 60% customer referral rate
3. Price advantage, Because we are factory, our price is 5%-10% lower than middleman and trafficker at same level
4. Our sales is peofessional and will give you Detailed answers for your concerns, and we have a strong technical team for your special needs,such as OEM and ODM service
5. Our Tenet: put coustomers in mind, Customer requirements are fundamental to us, we make different solutions accroding different requirements of customers
