SMD HD P4.8 Outdoor Rental LED Display Video Wall 110V - 220V AC 800W For Stage

SMD HD P4.8 Outdoor Rental LED Display Video Wall 110V - 220V AC 800W For Stage

SMD HD P4.8 Outdoor Rental LED Display Video Wall 110V - 220V AC 800W For Stage
SMD HD P4.8 Outdoor Rental LED Display Video Wall 110V - 220V AC 800W For Stage
SMD HD P4.8 Outdoor Rental LED Display Video Wall 110V - 220V AC 800W For Stage
Product Details:
Place of Origin: China
Brand Name: KAILITE
Certification: CE/UL/RoHS/ISO9001/FCC
Model Number: P4
Payment & Shipping Terms:
Minimum Order Quantity: 2 Square Meters
Price: Negotiation
Packaging Details: Wooden Case Packing ; Flight Case Packing for Rental cabinet
Delivery Time: 10-15 work days
Payment Terms: T/T, L/C, D/A, D/P,
Supply Ability: 8000 Square Meters Per Month
Contact Now
Detailed Product Description
Module Size: 256mm*128mm Module Resolution: 64*32
Color: Full Color Cabinet Size: Customized
Maximum Power: 800w Led Lamp: Smd1921
Brightness: >6500cd/square Meters Refresh Rate: ≥1200Hz
Brightness Control: Manual/Automatic
High Light:

SMD HD Outdoor Rental LED Display

,

P4.8 Outdoor Rental LED Display 110V

,

AC 800W Outdoor Rental LED Display



SMD HD P4.8 outdoor rental led display/outdoor led screen for stage/ led video wall for rental


Quick Details:


1, Pixel Pitch: 4mm. 5mm, 6.67mm
2, SMD LEDs, Wide viewing angle: 160°/ 140°.
3, Digital Process: 16bits.
4, Standard cabinet size: Customized, cabinet weight: 40kg/Sqm.
5, Grey Level: 16 Bit
6, Recommended minimum viewing distance: 5-7m.

7, Material: Die Casting Aluminum

8, Refresh Rate: 1920Hz

9, IP Rating: IP65



Specifications:

led module parameter
Technical parameters UNIT parameters Values
Pixel pitch mm 4
module size mm 256*128mm
Physical density dots/㎡ 62500
Pixel configuration RGB 1,1,1
Driving method   Constant current 1/8scan
Led lamp Smd 1921
module resolution dots 64*32
Module weight Kg 0.32
Ingress protection   IP65
Module consumption W 25
led display parameter
Viewing angle Deg. H120 V120
Viewing distance m 4-40
Maximum power W/㎡ 800w
Frame Frequency Hz ≥60
Refresh frequency Hz ≥1200
Equilibrium brightness cd/㎡ ≥1500
Working environment temperature 0C -30~60
Display working voltage VAC 220V±15%/110V±15%
Gray scale/color   ≥16.7M color
Input signal   RF S-Video RGB etc
Control system   Nova/Linsn control system
Mean free error time hours >5000
life time hours >100,000
Lamp failure frequency   <0.0001


Features:

  • High IP Rating IP65, good waterproof and dust resistance, suitable for every condition.
  • Wide viewing angle 160° for broader reach, seamless in all direction with same image quality output, suitable for large gatherings.
  • High brightness from 6,000nits to 9,000nits, visible from every direction even face to direct sunshine.
  • Good heat dissipation with fans and using meanwell power supply, long lifespan.
  • You can adjust the resolution by change modules directly, this can save your cost and labor.
  • 250x250mm module, compatible with various pitches such as PH2.6/PH2.9/PH3.9, high selectivity
  • High-precision and ultra-practical design, 500x500/1000mm cabinet, light and easy to assemble



After-sell Service:
2 yaers quality guarantee period for all parts
Lifetime free maintenance and software upgrade service. and if you have any problem in using the software you can contact us, and we will solve the problem for you in 24 hours

we will reponse you in 24 houres if you have any question about the led screen,

maintenance guidance and problem solution supplied in 48 hours.

Providing customer with the loading program, so they can use as soon as they install the
led screen,don't need to debug again

Free technical training for how to use and handle the software.

Customer satisfaction tracking report.



Application Of Outdoor Rental LED Display

Outdoor Rental LED Display is being an important advertising media for outdoor events and advertising campaign on basis of its unique advanced structure feature. It’s known as truck mounted LED display and trailer mounted LED screen. The products are widely used for advertising, shows, square, concert, sporting event, festival, corporate gathering or charitable event, Grand Theater, large song and dance party, fashion show.


FAQ:

1. Except this model, are there any other models?
yes, For indoor led screen we have p2.5 p3 p3.91 p4 p4.81 p5 p6 p7.62 p10
For outdoor led screen we have p5 p6 p8 p10

2. Are you factory? and your warranty?
yes we are 7 years factory, 2 years warranty and lifetime maintenance

3. What's the function of your led screen?
It supports videos, flash, WAV/MIDI, PPT, images and so on

4. What's your delivery time?
Wthin 7-21 days after we receiving deposit

5. What's your package and shipping way?
Goods are packed with wooden case or flight case; delivered by air shipping or sea shipping


SMD HD P4.8 Outdoor Rental LED Display Video Wall 110V - 220V AC 800W For Stage 0


SMD HD P4.8 Outdoor Rental LED Display Video Wall 110V - 220V AC 800W For Stage 1

 More details can direct contact me,my whatsapp/wechat is +86 13419630473
