P3 Indoor Rental LED Display Video Wall SMD2121 192x192mm Module for Stage Shows

P3 Indoor Rental LED Display Video Wall SMD2121 192x192mm Module for Stage Shows

  • P3 Indoor Rental LED Display Video Wall SMD2121 192x192mm Module for Stage Shows
  • P3 Indoor Rental LED Display Video Wall SMD2121 192x192mm Module for Stage Shows
  • P3 Indoor Rental LED Display Video Wall SMD2121 192x192mm Module for Stage Shows
  • P3 Indoor Rental LED Display Video Wall SMD2121 192x192mm Module for Stage Shows
P3 Indoor Rental LED Display Video Wall SMD2121 192x192mm Module for Stage Shows
Product Details:
Place of Origin: China (Mainland)
Brand Name: KAILITE
Certification: CE, FCC, ROHS
Model Number: P3
Payment & Shipping Terms:
Minimum Order Quantity: 2 Square Meters
Price: Negotiation
Packaging Details: Wooden case, Flight case
Delivery Time: 7-15 work days
Payment Terms: T/T
Supply Ability: 8000 Square Meters / Month
Contact Now
Detailed Product Description
Pixel Pitch: 3mm Panel Size: 192*192mm
Module Size: 192*96mm / 192*192mm Physical Density: 111111 Dots/sqm
Pixel Configuration: 1R1G1B Driving Method: Constant Current 1/16 Scan
LED Encapsulation: SMD2121 Display Resolution: 64*64
Module Power: 20W Viewing Angle: H120 V120 Degree
Optimum Viewing Distance: 3-20m Maximum Power: 860W
Frame Frequency: >=60Hz Refresh Frequency: >=1200Hz
Equilibrium Brightness: >=1400 Cd Ingress Protection: IP43
Life Time: >100,000 Hours
Highlight:

P3 Indoor Rental LED Display

,

SMD2121 192x192mm LED Module

,

Stage Shows LED Video Wall

P3 Indoor Rental LED Display Video Wall — SMD2121 192×192mm Module for Stage Shows

The KAILITE P3 indoor rental LED display is a fine-pitch SMD LED video wall purpose-built for rental fleets, AV hire companies and indoor events of every scale. With a modular 192 × 192 mm panel, SMD2121 LED lamps and a constant-current 1/16 scan design, it produces a smooth, high-contrast picture that holds its quality under studio lighting and on-camera capture. The lightweight cabinet is engineered to be assembled, hung and struck again and again, while redundant data paths and factory pixel calibration keep the picture consistent from the first panel to the last. For rental houses, event producers and integrators, this P3 SMD LED screen is a dependable performer that is ready for any indoor venue.

Key Features & Rental Advantages
  • Modular cabinet design delivers fast, tool-free installation and dismantling on tour.
  • Data hot backup protects the show against signal drop-outs by automatically switching redundant lines.
  • Refresh rate scalable up to 4200 Hz keeps the image completely flicker-free for live video and broadcast.
  • Superb brightness and color uniformity, with every panel pixel-calibrated before delivery.
Technical Specifications
Main Parameters Technical Parameters Unit Values
Module ParametersPixel PitchMM3
Panel SizeMML192 × H192
Physical Density/sqm111,111 Dots
Pixel ConfigurationR/G/B1,1,1
Driving Method—Constant current 1/16 scan
LED EncapsulationSMD2121
Display ResolutionDots64 × 64
Module PowerW20
Display ParametersViewing AngleDegH120 / V120
Option DistanceM3–20
Maximum PowerW860
Cabinet SizeMML586 × H586
Frame FrequencyHz≥60
Refresh FrequencyHz≥1200
Equilibrium BrightnessCD≥1400
Operation Temperature / Humidity°C-30~+45 / 10%~95%
Input VoltageVAC220V±10% / 110V±10%
Ingress Protection—IP43
Gray Scale / Color—≥16.7M color
Brightness Control—Manual / Automatic
Input Signal—RF / S-Video / RFB / etc
Control System—PCTV + DVI video card + control card + fiber
MTBFHours>5000
Life TimeHours>100,000
Lamp Failure Frequency—<0.0001
Our Services
Pre-sales Support
  • Technical consultation before purchase, so the configuration matches your project exactly.
  • Budget-friendly product selection that delivers the greatest value for rental or fixed installations.
  • Structural framework design and installation drawings produced for your LED display project.
  • Software customisation to suit your specific content, control and playback requirements.
After-sales Service
  • Extended warranty service that goes beyond the standard two-year term.
  • Free maintenance support covering remote configuration, technical consultation and troubleshooting.
  • Lifetime follow-up service, including continuous system function improvements and software upgrades.
  • Operator training for your team, covering daily operation and routine maintenance.
Frequently Asked Questions
1. Besides this model, which other models do you offer?

Yes. For indoor LED screens we produce P2.5, P3, P3.91, P4, P4.81, P5, P6, P7.62 and P10; for outdoor LED screens we produce P5, P6, P8 and P10.

2. Are you a factory, and what about your warranty?

Yes, we are an 8-year manufacturer offering a two-year warranty together with lifetime maintenance.

3. What can your LED screen do?

It supports videos, Flash, WAV/MIDI audio, PPT, images and more.

4. What is your delivery time?

Within 15–25 days after receiving the deposit.

5. How are the goods packaged and shipped?

Goods are packed in a wooden case or flight case and dispatched by air or by sea.
