| Place of Origin: | China |
| Brand Name: | KAILITE |
| Certification: | CE FCC ROHS |
| Model Number: | P4 |
| Minimum Order Quantity: | 5 Square Meters |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Case Packing ; Flight Case Packing |
| Delivery Time: | 8-22 work days |
| Payment Terms: | T/T, L/C, D/A, D/P, |
| Supply Ability: | 6000 Square Meters Per Month |
| Module Size: | 256mm*128mm | Module Resolution: | 64*32 |
|---|---|---|---|
| Color: | Full Color Indoor Led Screen | Cabinet Size: | 512mm*512mm |
| Maximum Power: | 860w | Led Lamp: | Smd2121 |
| Driving Method: | 1/16 Scan Constant Current | Warranty: | 2 Years |
| Brightness: | >1200cd/square Meters | Refresh Rate: | ≥1200Hz |
| System: | LInsn Or Nova | Input Voltage: | 110-220V AC±10% |
| High Light: | led screen rental,led video panels,Indoor Stage P4 Led Displays |
||
P4 512mm*512mm Die Casting Aluminum Rental Led Displays For Indoor Stage
Quick Details:
p4 indoor Die casting aluminum led cabinet for rental usage, easy and convenient
more than 1200cd/square meters brightness & more than 1200Hz refresh rate, and good visual effect
Supporting OEM service, Design the shape which you need
Easy to install, eaay to maintance, light weight, good appearance.
24 months warranty for our products and life time maintance
Specifications:
| led module parameter | ||
| Technical parameters | UNIT | parameters Values |
| Pixel pitch | mm | 4 |
| module size | mm | 256*128 |
| Physical density | dots/㎡ | 62500 |
| Pixel configuration | RGB | 1,1,1 |
| Driving method | Constant current 1/16scan | |
| Led lamp | Smd | 2121 |
| module resolution | dots | 64*32 |
| Module weight | Kg | 0.23 |
| Module port | HUB75 | |
| Module consumption | W | 20 |
| led display parameter | ||
| Viewing angle | Deg. | H120 V120 |
| Viewing distance | m | 4-35 |
| Maximum power | W/㎡ | 860w |
| Frame Frequency | Hz | ≥60 |
| Refresh frequency | Hz | ≥1200 |
| Equilibrium brightness | cd/㎡ | ≥1200 |
| Working environment temperature | 0C | -30~60 |
| Display working voltage | VAC | 220V±15%/110V±15% |
| Gray scale/color | ≥16.7M color | |
| Input signal | RF S-Video RGB etc | |
| Control system | Nova/Linsn control system | |
| Mean free error time | hours | ＞5000 |
| life time | hours | ＞100,000 |
| Lamp failure frequency | ＜0.0001 | |
Features:
1. Light weight: The aluminum die-casting technology makes the single cabinet as light as 8.2KG, which is convenient for assembly and disassembly
2. Hight refresh rate: Over 1200 Hz refresh rate to ensure the picture wrinkle-less,line-less and stable.
3. Low brightness and Hight gray scale:14Bit-16Bit gray scale to bring excellent performance when brightness is reduced to 25%.
4. Easy to install: Don't need to worry about the installation, it is easy, because of the design of the Die casting cabinet, Just like building block
5. High IP: The IP65 insures the reliable operation in different enrionment, and it is more safe
advantages:
1. Ultra Thin: the cabinet for p4 indoor rental led screen is Thin, so it is good looking and easy to disassembly and transport
2. Easy to maintain:No need to disassemble the whole screen for maintenance.Each component can be detached individually for that purpose.
3. Noiseless:The aluminum structure requires no fan.Combined with the noiseless power supply,the cabinet is totally silent.
Applications:
Now, with the development of society, led screen has been used to many areas, mainly divided into outdoor usage and indoor usage such as:
Outdoor advertising, indoor performance, outdoor and indoor rental bussiness, Public
places, Business usage.
For example: supermatket, restaurants, travelling agency, commercial plaza, Movie theaters,
clubs, commercial building, subway stations, airport stations, big outdoor advertising tv screen,
In all, many places need led screen for all kinds of usages, we just try our best to meet
the trends and needs, and do our best to make good products for our customers
After-sell Service:
Installation servive, usually we don't take charge of installing overseas, but we can
provide technical support for you. if you need installation service, we can send our
technicians to your country, but the customers need take charge of the cost
Lifetime free maintenance and software upgrade service. and if you have any problem in using the software you can contact us, and we will solve the problem for you in 24 hours
we will reponse you in 24 houres if you have any question about the led screen,
maintenance guidance and problem solution supplied in 48 hours.
Providing customer with the loading program, so they can use as soon as they install the
led screen,don't need to debug again
Free technical training for how to use and handle the software.
Customer satisfaction tracking report.
FAQ:
1.Except this model, are there any other models?
yes, For indoor led screen we have p2.5 p3 p3.91 p4 p4.81 p5 p6 p7.62 p10
For outdoor led screen we have p5 p6 p8 p10
2.Are you factory? and your warranty?
yes we are 7 years factory, 2 years warranty and lifetime maintenance
3.What's the function of your led screen?
It supports videos, flash, WAV/MIDI, PPT, images and so on
4.What's your delivery time?
Wthin 7-21 days after we receiving deposit
5.What's your package and shipping way?
Goods are packed with wooden case or flight case; delivered by air shipping or sea shipping
Contact Person: Mr.Liu
Tel: +8613510138815
