| Place of Origin: | Guangdong,China |
| Brand Name: | Kailite |
| Certification: | CE FCC ROHS |
| Model Number: | P6 outdoor |
| Minimum Order Quantity: | 5SQM |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Flight package and wood package |
| Delivery Time: | ahout 20 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1500SQM/per mouth |
| Item: | PH6 | Color: | Full-color Real Pixels |
|---|---|---|---|
| Use Environment: | Outdoor | Pixel Pitch: | 6mm |
| Module Size: | 192*192mm | Physical Density : | 27777dots/㎡ |
| Pixel Configuration : | 1R1G1B | LED Chip: | SMD3535 |
| Module Resolution: | 32*32 | Module Power: | 35w |
| Recommended Viewing Distance: | 6-70m | Best Viewing Angle : | H: 120°; V:120° |
| Maximum Power Consumption: | 900w | Average Power Consumption: | 480w |
| Cabinet Size : | W576×576mm | Standard Cabinet Resolution: | 96*96 |
| High Light: | smd led panel,led display smd |
||
P6 LED Video Screen 192*192mm Full-color real pixel 6mm 1R1G1B outdoor video
Description:
1. personalized and complete solution for your requirement
2. factory price and good quality
3. convenient and fast installation ,easy maintenance
Competitive advantages:
1. 9 years of experience in manufacturing LED screens of different application
2. Implementation of the project on the screen of any complexity
3. faster delivery products from China
4. engineers' experience for 8 years
5. Technical Support (from design to debug screen display)
| Item | P6 |
| Color | Full-color real pixels |
| Use environment | Outdoor |
| Pixel pitch | 6mm |
| Module size | 192*192mm |
| Physical density | 27777dots/㎡ |
| Pixel configuration | 1R1G1B |
| LED chip | SMD3535 |
| Module resolution | 32*32 |
| Module power | 35w |
| Recommended viewing distance | 6-70m |
| Best viewing angle | H: 120°; V:120° |
| Maximum power consumption | 900w |
| Average power consumption | 480w |
| Cabinet size | W576m×H576mm |
| Standard cabinet resolution | 96*96 |
| Driving method | 1/8Scan, Constant Current |
| Video frame rate | ≥60 Hz |
| Rate refresh | ≥1200Hz |
| White balance brightness | ≥6500cd |
| Operating temperature/Humidity | -30℃~+45℃ |
| Ingress protection | Front:IP 67; Back:IP65 |
| Input voltage | 110-220V AC±10% |
| Gray scale /Color | Display Colors ≥16.7N(Synchronize) |
| Brightness control | Manual/Automatic |
| Input signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc |
| Control system | PCTV+DVI video card+control card+fiber |
| MBTF | >5000 hours |
| Life time | >100,000 Hours |
| The rate | <0.0002 |
Packaging&shipping:
Flight package and wood packge can be choosed
Our after-services:
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your query in fluent English
3.Customized design is available,OEM & ODM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5. Special discount and protection of sales area provided to our distributor.
6. Warmly welcome your visit in our company if available.
7. Warranty: 24 months, a little investment for longer warranty time.
