1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution

1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution

  • 1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution
  • 1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution
  • 1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution
1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution
Product Details:
Place of Origin: Guangdong,China
Brand Name: Kailite
Certification: CE FCC ROHS
Model Number: P10 outdoor
Payment & Shipping Terms:
Minimum Order Quantity: 5SQM
Price: Negotiation
Packaging Details: Flight package and wood package
Delivery Time: ahout 20 days
Payment Terms: L/C, T/T
Supply Ability: 1500SQM/per mouth
Contact Now
Detailed Product Description
Item: PH10 Color: Full-color Real Pixels
Use Environment: Outdoor Pixel Pitch: 10mm
Module Size: 320*160mm Physical Density : 10000dots/㎡
Pixel Configuration : 1R1G1B LED Chip: SMD3535
Module Resolution: 32*16 Module Power: 45w
Recommended Viewing Distance: 10-70m Best Viewing Angle : H: 120°; V:120°
Maximum Power Consumption: 850w Average Power Consumption: 420w
Cabinet Size : W960×960mm Standard Cabinet Resolution: 96*96
High Light:

outdoor led panel

,

indoor led video walls

1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution


advantages:

1. Many Years factory, We are led screen manufacturer for 7 years, we have rich experience in outdoor and indoor led display, quality is guaranteed


2. Price advantage, Because we are factory, our price is 5%-10% lower than middleman and trafficker at same level


3. Our sales is peofessional and will give your Detailed answers for your concerns, and we have a strong technical team for your special needs,such as OEM and ODM service


4. Our Tenet: put coustomers in mind, Customer requirements are fundamental to us, we make different solutions accroding different requirements of customers



Description:

1. personalized and complete solution for your requirement
2. factory price and good quality
3. convenient and fast installation ,easy maintenance


Competitive advantages:

1. 9 years of experience in manufacturing LED screens of different application
2. Implementation of the project on the screen of any complexity
3. faster delivery products from China
4. engineers' experience for 8 years
5. Technical Support (from design to debug screen display)



Item P10
Color Full-color real pixels
Use environment Outdoor
Pixel pitch 10mm
Module size 320*160mm
Physical density 10000dots/㎡
Pixel configuration 1R1G1B
LED chip SMD3535
Module resolution 32*16
Module power 45w
Recommended viewing distance 10-70m
Best viewing angle H: 120°; V:120°
Maximum power consumption 850w
Average power consumption 420w
Cabinet size W960m×H960mm
Standard cabinet resolution 96*96
Driving method 1/4Scan, Constant Current
Video frame rate ≥60 Hz
Rate refresh ≥1200Hz
White balance brightness ≥5500cd
Operating temperature/Humidity -30℃~+45℃
Ingress protection Front:IP 67; Back:IP65
Input voltage 110-220V AC±10%
Gray scale /Color Display Colors ≥16.7N(Synchronize)
Brightness control Manual/Automatic
Input signal RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Control system PCTV+DVI video card+control card+fiber
MBTF >5000 hours
Life time >100,000 Hours
The rate <0.0002



1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution 0

1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution 1

1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution 2

1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution 3







1R1G1B P10 HD Led Display Video With Two Year Warranty / Unique Solution 4



Packaging&shipping:



Flight package and wood packge can be choosed



Our after-services:

1. Reply your inquiry in 24 working hours.

2. Experienced staffs answer all your query in fluent English

3. Customized design is available,OEM & ODM are welcomed.

4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.

5. Special discount and protection of sales area provided to our distributor.

6. Warmly welcome your visit in our company if available.

7. Warranty: 24 months, a little investment for longer warranty time.
