Wall p4.81 p3.91 Front Maintenance Led Display Board 500 x 500 / 500 x 1000 with Nova system
-
-
Large Image :
Wall p4.81 p3.91 Front Maintenance Led Display Board 500 x 500 / 500 x 1000 with Nova system
|
Product Details:
| Place of Origin: |
Shenzhen, China(mainland) |
| Brand Name: |
OEM/ODM |
| Certification: |
CE,FCC,ROHS ISO9001 |
| Model Number: |
P3.91 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
2 suqare meter |
| Price: |
Negotiation |
| Packaging Details: |
wooden case/ flight case packing |
| Delivery Time: |
5--20 working days |
| Payment Terms: |
D/A, D/P, L/C, T/T, Western Union, MoneyGram |
|
Detailed Product Description
| Configuration: |
SMD2121 Black |
Module Dimension: |
(W)250mm X(H)250mm |
| Panel Dimension: |
(W)500mmx (H) 500/1000mm |
Pixel Density: |
65536dots/m2 |
| Flatness Error: |
≤0.1mm |
Brightness: |
>1200cd/m2 |
| Panel Structure: |
Die-casting Aluminum |
Maintenance: |
Front |
Wall p4.81 p3.91 Front Maintenance Led Display Board 500 x 500 / 500 x 1000 with Nova system
Technical parameters
| |
UNIT |
Parametersvalues |
| Pixel pitch |
MM |
3.91 |
| Panel size |
MM |
L250XH250 |
| Physical density |
/M2 |
65536 |
| Pixel configuration |
R/G/B |
1,1,1 |
| Driving method |
|
Constant current 1/16scan |
| LED Encapsulation |
SMD |
2121 |
| Display resolution |
DOTS |
64X64=4096dots |
| Module weight |
KG |
0.5 |
| Module port |
|
HUB75-B |
| Module working voltage |
VDC |
5 |
| Module consumption |
W |
20 |
What material we use:
- LED chip : Cree,Nicha,Epistar,Opto,Silan etc
- IC brand : MBI,TI,SONY,TOSHIBA,SITI,NXPSemiconductors etc.
- Power supply : Meanwell
- Control card : Nova,Linsn, DBstar,colorlight etc
What service we offer:
- We are available in 24 /7.
- Provide free solution, technical support and training
- Extend warranty free if excess certain amount
- Delivery with lowest cost& fastest shipping way
Packaging & Shipping
- Package: wooden case/flight case/carton box.
- Shipping: By air, From factory to the most closed air port of destination. By world wide express, always use DHL,UPS, TNT, Fedex, EMS, door to door service. By ship, the slowest shipping, from factory to the most closed sea port of destination.
FAQ:
- How to help client choose suitable display ?
(1) the needs of displaying content
(2) visible distance,visual angle confirm
(3) requirements of cabinet resolution
(4) requirements of installation environment
(5) cost control
- What factors should be taken into consideration of screen size design ?
----There is three important factors in designing screen size:
(1) need of displaying content
(2) conditions of field and space
(3) unit template size (indoor display) or pi, xel size (outdoor display)
- What are the index on the power consume and the requirements for the power supply of the LED screen? ----The power consume of the LED screen have the Average power consume and the Maximum power consume. We also called the Average power consume as the Working power consume, it’s the factual power consume when it’s operating normally. The Maximum power consume is the power consume when it’s starting or full lighting and the other extreme situations.
