High Brightness Led Stage Backdrop Pitch 3.91mm IP65 Nova / Linsn System

China High Brightness Led Stage Backdrop Pitch 3.91mm IP65 Nova / Linsn System supplier
High Brightness Led Stage Backdrop Pitch 3.91mm IP65 Nova / Linsn System supplier High Brightness Led Stage Backdrop Pitch 3.91mm IP65 Nova / Linsn System supplier

Large Image :  High Brightness Led Stage Backdrop Pitch 3.91mm IP65 Nova / Linsn System

Product Details:

Place of Origin: Shenzhen, China(mainland)
Brand Name: OEM/ODM
Certification: CE,FCC,ROHS ISO9001
Model Number: P3.91

Payment & Shipping Terms:

Minimum Order Quantity: 2 suqare meter
Price: Negotiation
Packaging Details: wooden case/ flight case packing
Delivery Time: 5--20 working days
Payment Terms: T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability: 8000sqm per month
Contact Now
Detailed Product Description
Model Number: P3.91-SMD Usage: Indoor
LED Encapulation: Smd 2121 Cabinet Size: 500*500mm
Cabinet Weight: 7kg Optional: P2.5,P3,P4,P5,P6,P8
Viewing Distance: >4m IP: 65



Indoor high brightness Pitch 3.91mm Stage LED Screen panel with Nova or Linsn system



Product feature



1) High precision LED, improve the smooth of the screen;
2) Slim& light cabinet, easy to move and install for LED rental;
3) Die Cast Aluminum Cabinet, durable and won't deform;
4) High grey level, high refesh rate,high definition
5) Support Different Input and output signals.





Application:



----Comercial advertising Indoor full color led panel , Stadium perimeter Indoor full color led panel , Mobile trailer Indoor full color led panel for mobile media,shopping mall Indoor full color led panel full color led panel for logo showing,bank&stock exchange Indoor full color led panel for rates showing, train & bus station Indoor full color led panel , air port full color led panel , telecommunication full color led panel system for information showing and instruction.





Specification:



Pitch 3.91mm full color 1/16 scan)
Technique SMD
Pixel structure 1R1G1B 3in1
Pixel pitch 3.91mm
Pixel density 65536 dots
Brightness 1300cd
Module dimension 250mm(W) * 250mm(H)
Module resolution 52 pixel(W) * 52pixel mm(H)
Cabinet dimension 500 * 500mm
Cabinet resolution 64* 64
Cabinet area 0.25sq. meter
Optimal visual distance >4m
Visual angel 140 degree (H/V)
Max power consumption 860w
Module power 20w
Brightness adjustment Adjust according to the environment
brightness software (0%-100% adjustable)
Gray scale point by point 256 gray grade levels of
each color, 16 bits γ correction available
Drive mode 1/16 dynamic scan, constant current
Frame frequency ≥60HZ
Refresh frequency ≥1200HZ
Input voltage AC 110~220 volts
Operation temperature - 40℃~ +60℃
Operation humidity 10%~90%
Input signal video, s-videl, RGB digital signal etc.
Inout signal S-video, RF, RGB, Yuv, YC, composite…
Control system DVI card + master control card + receiver card
MTBF >5000 hrs
Life span (50% brightness) 100, 000 hrs
Malfunction dot rate 1/10000
Ingress protection rate IP65
Cabinet material Aluminum / iron
Application: Rental / Permanent installation available





FAQ


1. Can we make any size of led display?
Nope, according the led module size and cabient size, such as P3.91mm is 500x500mm for smallest unit.



2,What's best size of led display?
The best aspect ratio of LED display are W16:H9 or W4:H3


3,How to install led display?
We will provide drawing of steel structure or hanging truss,then you can install led display very easy.


4,How to order LED display?
Please tell me indoor or outdoor do you need,size of led display,where will be application of led display.


5,How to shipment?
Seaway and airway shipping both are ok. P3.91mm alos can be shipped by air and dhl, becaUse the value is higher than other product.


6,How to payment?
You can transfer payment by TT,western union.
