SMD P4 P5 portable HD Led Display Outdoor High brightness Energy saving

Good quality SMD Led Screen for sales
Good quality SMD Led Screen for sales
This is my third time doing business with them, The quality of their led screen is very stable, and have a intimate after service!

—— Nick

I am mykola from Romania. doing business with them is just no worries. they are very considerate, this is what i am always finding

—— Mykola

I'm Online Chat Now

SMD P4 P5 portable HD Led Display Outdoor High brightness Energy saving

China SMD P4 P5 portable HD Led Display Outdoor High brightness Energy saving supplier
SMD P4 P5 portable HD Led Display Outdoor High brightness Energy saving supplier SMD P4 P5 portable HD Led Display Outdoor High brightness Energy saving supplier

Large Image :  SMD P4 P5 portable HD Led Display Outdoor High brightness Energy saving

Product Details:

Place of Origin: China
Brand Name: KAILITE
Certification: CE FCC ROHS
Model Number: P8

Payment & Shipping Terms:

Minimum Order Quantity: 2 Square Meters
Price: Negotiation
Packaging Details: Wooden case ; Flight case
Delivery Time: 8-16 work days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 6000 Square Meters Per Month
Contact Now
Detailed Product Description
Pixel Pitch: 8mm Module Size: 256*128mm
Module Resolution: 32*16 Panel Dimensions(W×H×D): 40.3×40.3inch
Pixel Configuration: 3-in-1 SMD Gray Scale Per Color: 65536
Colors: 281 Trillion MBTF: 5000 Hours



SMD P4 P5 portable HD Led Display Outdoor High brightness Energy saving





Advantage

Seamless connection
The precision of cabinet reach 0.05m so as to achieve seamless assembly.


Easy to maintain
There is almost no more ribbon cables for the cabinet and module. Everything connected straight on the PCB hub. Less cables means less possible problems.


High brightness
For our outdoor HD LED Display series (P3.91, P4.81, p6, P8), brightness: approx 6500 (Standard Adjusted). The higher brightness than conventionally spliced screens make the picture more colorful and vivid even in bright environments.

High refresh rate
The driving IC is using model of MBI5124 for high performance. The chips can generate a speed of > 1200 refresh rate to ensure the picture wrinkle-less, line-less and stable.

High Gray scale
It is because we use the highest technology of driving chips that also will improve the Gray scale .



Parameter



Parameters Value Unit
Pixel pitch 8 mm
Brightness More than 6500 nit
Panel dimensions(W×H×D) 1024×1024 mm
Panel dimensions(W×H×D) 40.3×40.3 Inch
Panel material Aluminum or Steel Iron /
Weight 40 kg/panel
Pixel configuration 3-in-1 SMD /
Module dimensions (W×H) 256*128 mm
Module dimensions (W×H) 10.1*10.1 Inch
Pixel matrix per panel 128×128 pixels
Pixel density 15625 pixels/sq.m.
Refresh rate ≥6500 Hz
Gray scale per color 65536 level
Colors 281 Trillion /
Viewing angle(H/V) 160/120 deg.
IP rating(Front/Rear) IP65/IP54 /
Power consumption(max/avg) 850/400 W/sq.m.
Input voltage(AC) 110~240 V
Operating temperature -40 ~65 °C
Operating humidity 10%~90% /
Source compatibility(with video processor) AV, S-Video, VGA, DVI, HDMI, SDI, DP /





Why Choose us?



" You choose us, we give you high quality products service"



LED display industry in rapidly developing, the competition in fierce, only high quality products to win the market for long time.Shenzhen Kailite Optelectronics co.,ltd is led screen manufacturer for 9 years.



(1) With Powerful and experienced engineers and technician team, with advanced
production equipment,we control all steps from material to finished product,
from design to produce that guarantee the quality and reliability.



(2) New style module mast which can improve 10% brightness than normal module mask
and realize more clearer images with stronger feeling of layers



(3) Excellent quality that pass CE FCC with low power consumption, High brightness, Long Life spam and easy to installation



(4) If you require for projects installation,our engineer can go to instruct you how to install the led screen.



(5) Free training after order, and offer you the train course in detail.



(6) The best competitive price at the market with the same even high quality.



SMD P4 P5 portable HD Led Display Outdoor High brightness Energy saving
