SMD P6 Outdoor Video Stage Background LED Screen Board High Definition

Good quality SMD Led Screen for sales
Good quality SMD Led Screen for sales
This is my third time doing business with them, The quality of their led screen is very stable, and have a intimate after service!

—— Nick

I am mykola from Romania. doing business with them is just no worries. they are very considerate, this is what i am always finding

—— Mykola

I'm Online Chat Now

SMD P6 Outdoor Video Stage Background LED Screen Board High Definition

China SMD P6 Outdoor Video Stage Background LED Screen Board High Definition supplier
SMD P6 Outdoor Video Stage Background LED Screen Board High Definition supplier SMD P6 Outdoor Video Stage Background LED Screen Board High Definition supplier

Large Image :  SMD P6 Outdoor Video Stage Background LED Screen Board High Definition

Product Details:

Place of Origin: China
Brand Name: KAILITE
Certification: CE FCC ROHS
Model Number: P6

Payment & Shipping Terms:

Minimum Order Quantity: 1 Square Meters
Price: Negotiation
Packaging Details: Flight box
Delivery Time: 7-14 work days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 6500 Square Meters Per Month
Contact Now
Detailed Product Description
Item: P6 Led Video Board Module Resolution(dots): 32*32
Module Size: 192mm*192mm Pixel Configuration(RGB): SMD 3 In 1
Working Voltage: 220V±15% OR 110V±15% Wavelength: R 620-625 G 520-525 B 470-475



SMD P6 Outdoor Video Stage Background LED Screen Board High Definition



Advantages



1) It is very easy to calculate the size of LED screen.It can be exactly 4*3m, 6m*4m, 8m*4.5m etc. ( 4m*3m is 4:3 ratio and 8m*4.5m is 16:9 ratio,perfect to show video )



2) Ultra-thin and Super-light: only 7.8KG per cabinet of 500mmW*500mm Hand 12.8 KG per cabinet of 500mm W*1000mm H and depth is only 75mm, can stand on floor independently.



3) 500*1000mm cabinet can work with our 500*500mm die-casting aluminum cabinet so the height of LED screen can be both 1m and 0.5m



4) The appearance is very simple and elegant,looks very high end



5) With specially designed fast lock system, easy to install and dismantle



6) The new structure design enables diversified installation to meet the hanging-up and stacking requirements.



7) High contrast rate up to 5000:1 by using black LED



8) High refresh rate with NOVA control system,no scaning line when photographed.



9) Due to the light weight and low power consumption, it can reduces the labor cost,operating cost and transportation cost





Model No.

P6

Pixel Pitch

6mm

Module Size

192*192mm

Module Resolution(pixels)

32*32

Cabinet Size

576mm×576mm

Panel Resolution(pixels)

96×96

Pixel Configuration(RGB)

SMD 3 in 1

Pixel Density(pixels)

27777

Brightness(cd)

6500

Best Viewing Distance(m)

6-150

Average Power Consumption(W)

850

Waterproof Level

IP65

Drive Method

1/8scan

LED SPEC

3535

Viewing Angle

140°(H)/140°(V)

Operating Temperature

–40~100

Video Frame Rate(Hz)

≥ 60HZ

Display Refresh Rate(Hz)

≥ 1200HZ

Grey Level(colors)

16.7million

MTBF

≥50,000 hours

Lifespan

≥100,000Hours

Working Voltage

220V±15% OR 110V±15%

Wavelength

R 620-625 G 520-525 B 470-475

Graphics Card

DVI Graphics card

Video Signal

RF, S-Video, RGB, RGBHV, YUV, YC, etc.

Control System

LINSN Nova



Company



shenzhen kailit eoptelectronic co.,ltd is specialized in produce LED display. We are expert in rental LED display field . We have strong research and development ability. Our product is ultra-thin and super-light . By using high end LED and die-casting aluminum cabinet ,our product quality is very high but prices are very competitive too.Welcome to inquire and we will respond in 24 hours.



Our rental series LED display is the most popular in market now. Available models: P3.91,P4, P4.81, P5.68, P5.95 and P6.25. We produce a lot each month so we have good prices and very stable quality.Please send an inquiry for more information.



Service



1. Two years quality warranty
2. Free Technical Training

3. Software Upgrade



SMD P6 Outdoor Video Stage Background LED Screen Board High Definition
