Place of Origin: | Shenzhen, China(mainland) |
Brand Name: | Kailite |
Certification: | CE,FCC,ROHS ISO9001 |
Model Number: | P6 |
Minimum Order Quantity: | 2 suqare meter |
---|---|
Price: | Negotiation |
Packaging Details: | wooden case/ flight case packing |
Delivery Time: | 5--20 working days |
Payment Terms: | T/T, D/A, D/P, L/C, Western Union, MoneyGram |
Supply Ability: | 8000sqm per month |
Usage: | Indoor | Pixels: | 6mm |
---|---|---|---|
LED Chip: | Cree + Nichia + Epistar + Opto + Sila | Cabinet Material: | Die Cast Aluminum |
Display Function: | Video | Warranty:: | Two Years |
Highlight: | led video wall rental,rental led display |
P6 Stage Background Big Outdoor Rental Led Screen With Remote Control Novastar System
Led Display Features:
1. First-class LED chip: Epistar from Taiwan.
2. With pure golden wire connection in LED.
3. Grand A raw material for module frame and mask.
4. 4 layers PCB and copper plating thickness > 18mil.
5. Ag alloy solder paster to ensure good soldering on PCB.
6. Stainless steel screws when assembly.
7. Long-term Brightness capacity throughout product lifetime.
8. Easy Installation & User-friendly software.
9. Two years warranty.
Parameter | KP6 | |
Basic Parameter |
Pixel Configuration | SMD 3 in 1 |
Pixel Pitch (mm) | 6.0mm | |
Pixel Density | 27,777 pixels/m2 | |
Module Dimension (W*H) | 192*192MM | |
Cabinet Dimension(W*H*D) | 576*576*120mm | |
Weight | 50KG/sqm | |
Cabinet Material | Die-cast Aluminum | |
Optical Parameter |
Color Grayscale (bit) | 16bit |
Frame Frequency (Hz) | 50/60Hz | |
Brightness (nit) | 2,000 cd/m2 | |
Viewing angle | 140°/140° | |
Flatness error | ≤0.5mm | |
Using Parameter |
Working Voltage (V) | AC: 100-240V(50/60 Hz) |
Max. Power Consumption | 450 W/cabinet | |
Storage Temperature (°C) | -20~60 | |
Operating Temperature (°C) | -10~40 | |
Storage Humidity (RH) | 10%~90% | |
Operating Humidity (RH) | 10%~90% | |
IP Rating (Front / Rear) | IP65 | |
Lifetime Typical Value (hrs) | 50,000 |
1) Guidance service: We can guide on line if customers have questions about the installation and usage.
For large project, we provide your engineer a week free training, or if customer could bear the relevant cost,
our engineer can go to customer’s country for on-site guidance.
2) Warranty period: 2 years after shipment.
3) Maintenance principles: response in time, solve problems as soon as possible and ensure the use.
4) Maintenance terms: In the Maintenance period, free of all maintenance charges.
Under normal use and storage, our company will be responsible for the equipments.
If there is any failure in product quality, our company will maintain and change the components for free.
After Maintenance period, only charge the material costs fees free of manual work fees.
1. Can we make any size of outdoor rental led display?
Nope, according the led module size and cabient size, such as p6 outdoor led display, the smallest unit size is: 576*576mm.
2,What's best size of outdoor rental led display?
The best aspect ratio of outdoor rental led display are W16:H9 or W4:H3
3,How to install outdoor rental led display?
We will provide drawing of steel structure or hanging truss,then you can install outdoor led display very easy.
4,How to order outdoor LED display?
Please advise the approx size of outdoor led display you want to have, and the view distance or the pixel you need.
5,How to shipment?
Normally,our outdoor led display will be shipped by air and express (DHL,Fedex.UPS) and in container by sea for the mass order
