Outdoor Waterproof RGB LED Module SMD P6 Full Color 192 * 192 mm 1/8 Scan

Outdoor Waterproof RGB LED Module SMD P6 Full Color 192 * 192 mm 1/8 Scan

  • Outdoor Waterproof RGB LED Module SMD P6 Full Color 192 * 192 mm 1/8 Scan
  • Outdoor Waterproof RGB LED Module SMD P6 Full Color 192 * 192 mm 1/8 Scan
  • Outdoor Waterproof RGB LED Module SMD P6 Full Color 192 * 192 mm 1/8 Scan
Outdoor Waterproof RGB LED Module SMD P6 Full Color 192 * 192 mm 1/8 Scan
Product Details:
Place of Origin: China
Brand Name: KAILITE
Certification: CE FCC ROHS
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: 3 Square Meters
Price: Negotiation
Packaging Details: Wooden Case Packing ; Flight Case Packing
Delivery Time: 8-15 work days
Payment Terms: T/T, L/C, D/A, D/P
Supply Ability: 9000 Square Meters Per Month
Contact Now
Detailed Product Description
Module Size: 192mm*192mm Module Resolution: 32*32
Color: Full Color Cabinet Size: 576mm*576mm
Maximum Power: 900w Led Lamp: Smd3535
Driving Method: 1/8 Scan Constant Current Warranty: 2 Years And Life Time Maintenance
Life Time: >100,000 Hours LED Lamp: SanAn With MBI5124 IC
High Light:

led rgb module


led panel module

Outdoor Waterproof SMD P6 Full Color LED Module 192 * 192 mm 1/8 Scan
Quick Details:
P6 outdoor led modules 192mm*192mm with SanAn led lamp and MBI 5124 IC and 4 layers 1.6mm PCB
More than 1200Hz refresh rate with no shadows, and More than 6500 nits brightness every square meter
supporting OEM/ODM service, According your requirements, design and make the right shape and solution for you
Good and Famous Control system: Nova / Linsn
2-3 years warranty, lifetime maintance

led module parameter
Technical parametersUNITparameters Values
Pixel pitchmm6
module sizemm192*192
Physical densitydots/㎡27777
Pixel configurationRGB1,1,1
Driving method Constant current 1/8scan
Led lampSmd3535
module resolutiondots32*32
Module weightKg0.315
Module port HUB75
Module consumptionW
led display parameter
Viewing angleDeg.H120 V120
Viewing distancem6-70
Maximum powerW/㎡900w
Frame FrequencyHz≥60
Refresh frequencyHz≥1200
Equilibrium brightnesscd/㎡≥6500
Working environment temperature0C-30~60
Display working voltageVAC220V±15%/110V±15%
Gray scale/color ≥16.7M color
Input signal RF S-Video RGB etc
Control system Nova/Linsn control system
Mean free error timehours>5000
life timehours>100,000
Lamp failure frequency <0.0001

Stable & Good quality: The quality of all our raw materias is stable, and our strick production qualithy control. so the result is good and we also have a good reputation in this industry
Supporting OEM/ODM service, we will make a complete solution for you according our customers requirements
Supporting many play files: videos, texts, pictures,graphics, PPT, Flashes and any sources
from TV,VCD,DVD and so on
HD & high refresh rate: Every square meters has 27777dots/sqm, and the refresh rate is more than 1200Hz
Full color: adopt SMD3535 3 in 1 led lamps, excellent color performance and show the
content of the video best and reality
Waterproof led module and cabinet; Easy maintance & installation; relative low power
consumption; wide viewing angle, each module can be repaired, so it is easy and not will cost you much
1. 9 Years factory, We are led screen manufacturer for 9 years, we have rich experience in
outdoor and indoor led display, quality is guaranteed, also is our life.
2. Price advantage, Because we are factory, our price is 5%-10% lower than middleman and
trafficker at same level
3. Professional sales and technical team of 35 people to ensure perfect results
4. Service Advantage: From inquiry to order, we will give you considerate Service. response in 24 hours, from Placing order to delivery to your place, we will track and feedback to you!
5. Our Tenet: put coustomers in mind, Customer requirements are fundamental to us, we make
different solutions accroding different requirements of customers
After-sell Service:
Installation servive, usually we don't take charge of installing overseas, but we can
provide technical support for you. if you need installation service, we can send our
technicians to your country, but the customers need take charge of the cost
Lifetime free maintenance and software upgrade service.
we will reponse you in 24 houres if you have any question about the led screen,
any questions and concerns will be responsed prompt, our after-sales are well trained, the will give you best solutions and answers
Providing customer with the loading program, so they can use as soon as they install the
led screen,don't need to debug again
Free technical training for how to use and handle the software.
Customer satisfaction tracking report. we will call back to our cutomers every month to check out for the led screen
1. Except this model, are there any other models?
yes, For indoor led screen we have p2.5 p3 p3.91 p4 p4.81 p5 p6 p7.62 p10
For outdoor led screen we have p5 p6 p8 p10
2. Are you factory? and your warranty?
yes we are 7 years factory, 2 years warranty and lifetime maintenance
3. What's the function of your led screen?
It supports videos, flash, WAV/MIDI, PPT, images and so on
4. What's your delivery time?
Wthin 7-21 days after we receiving deposit
5. What's your package and shipping way?
Goods are packed with wooden case or flight case; delivered by air or sea
