Place of Origin: | Shenzhen China |
Brand Name: | KAILITE |
Certification: | CE RoHS ISO9001 UL FCC CCC |
Model Number: | P8 |
Minimum Order Quantity: | 2 square meters |
---|---|
Price: | Negotiation |
Packaging Details: | Wooden case/Flight case |
Delivery Time: | about 22-24 days |
Payment Terms: | T/T, L/C, D/A, D/P, MoneyGram, Western Union |
Supply Ability: | 8000 square meters per month |
Product Name: | P8 Outdoor LED Signs | Pixel Pitch: | 8mm |
---|---|---|---|
Screen Dimension: | Customized | Power Supply: | Meanwell/Rong Electric/G-energy/YouYi |
Application: | Square Building Ads Billboard | Refresh Rate: | 1920-3840Hz |
Highlight: | Remote Control Outdoor Full Color Led Display,Building Outdoor Full Color Led Display,ISO9001 Outdoor LED Signs |
Remote Control Outdoor Full Color Led Display Square Building Signs
Remote Control Outdoor LED Signs For Products Information By Wifi USB
Quick details of P8 Outdoor LED Signs
1. Scan method: 1/5 Scan, constant current.
2. Module size: 320*160mm
3. Module resolution: 40×20
4. Best viewing distance: ≥8m
5. Cabinet material: Iron or aluminum
Specification of P4 P5 P8 P10 Outdoor LED Signs
Item | P4 | P5 | P8 | P10 |
Pixel pitch | 4mm | 5mm | 8mm | 10mm |
Module size | 320*160mm | 320*160mm | 320*160mm | 320*160mm |
Module resolution | 80×40 | 64×32 | 40×20 | 32×16 |
Physical density | 62500 dots/㎡ | 40000 dots/㎡ | 15625 dots/㎡ | 10000 dots/㎡ |
LED type | SMD1921 | SMD1921 | SMD3535 | SMD3535 |
Cabinet size | 960×960×mm | 960×960×mm | 960×960×mm | 960×960×mm |
Cabinet resolution | 240×240 | 192×192 | 120×120 | 96×96 |
Cabinet material | Iron or aluminum | Iron or aluminum | Iron or aluminum | Iron or aluminum |
Maintenance way | Rear | Rear | Rear | Rear |
Best viewing distance | ≥4m | ≥5m | ≥8m | ≥10m |
Best viewing angle | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° |
Driving method (Constant Current) | 1/10Scan | 1/8 Scan | 1/5 Scan, | 1/2 Scan |
Video frame rate | ≥60 Hz | ≥60 Hz | ≥60 Hz | ≥60 Hz |
Refresh rate | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz |
Brightness | ≥5500nits | ≥5500nits | ≥6000nits | ≥6000nits |
Grey Level | 12-16bit | 12-16bit | 12-16bit | 12-16bit |
Ingress protection | IP65 | IP65 | IP65 | IP65 |
Life Time | >100,000 Hours | >100,000 Hours | >100,000 Hours | >100,000 Hours |
The rate | <0.0002 | <0.0002 | <0.0002 | <0.0002 |
Features of Outdoor LED Signs
1. High contract, 12-16 bits grey color.
2. Remote control by Wifi/USB/sim card with cellphone or computer.
3. Use brand lamps such as Nationstar, Kinglight.
4. Check every area of the screen, try our best to be flawless.
5. Low power consumption.
Applications:
Almost everywhere which you go through every day. Shopping malls, Bus station, Subway, Hospital, School, Large sports playground, Baseball field etc. With high brigthness and great protection from dust and moisture, they are used at outdoor places quite a lot and keep working for a long time.
After-sell Service:
1. Installation guidance by experienced staff online.
2. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
3. Warranty service.
4. Free technical training for how to use and handle the software.
FAQ:
1. What trade terms do you support?
We usually do EXW, FOB, CIF, DDU, DDP terms.
2. Are you trading company or manufacturer?
We are a 14 years leading factory, specialzied in led screen industry.
3. What is the control system?
Novastar/LINSN/Colorlight for synchronous system, Novastar/Huidu for asynchronous system. we have several options for customer.
4. What is LED screen common size?
16:9 and 4:3 aspect ratio is popular.
5. I don't know how to do custom clearance and pay duty, what should I do?
We can offer DDP door to door service.
