| Place of Origin: | Shenzhen China |
| Brand Name: | KAILITE |
| Certification: | CE RoHS ISO9001 UL FCC CCC |
| Model Number: | P8 |
| Minimum Order Quantity: | 2 square meters |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case/Flight case |
| Delivery Time: | about 22-24 days |
| Payment Terms: | T/T, L/C, D/A, D/P, MoneyGram, Western Union |
| Supply Ability: | 8000 square meters per month |
| Product Name: | P8 Outdoor Fixed Led Display | Pixel Pitch: | 8mm |
|---|---|---|---|
| Module Size: | 320*160 | Module Resolution: | 40*20 |
| Screen Dimension: | Customized | Brightness: | ≥6000nits |
| Cabinet Material: | Iron Or Aluminum | Application: | Outdoor Poster Billboard Signage Stage Performance |
| Color: | Full Color | Life Span: | 100000 Hours |
| High Light: | P10 Outdoor Fixed LED Display,P5 Outdoor Fixed LED Display,P8 Programmable LED Display |
||
Programmable P4 P5 P8 P10 Outdoor Fixed LED Display For Poster BillBoard
Digital Programmable P4 P5 P8 P10 Outdoor Fixed LED Display for Poster BilL Board
Quick details of P8 Outdoor Fixed LED Display
1. Cabinet size: 960*960mm
2. Cabinet resolution: 120*120
3. LED type: SMD3535
4. Physical density: 15625 dot/ m2
5. Warranty: 2 years
Specification of P4 P5 P8 P10 Outdoor Fixed LED Screen
| Item | P4 | P5 | P8 | P10 |
| Pixel pitch | 4mm | 5mm | 8mm | 10mm |
| Module size | 320*160mm | 320*160mm | 320*160mm | 320*160mm |
| Module resolution | 80×40 | 64×32 | 40×20 | 32×16 |
| Physical density | 62500 dots/㎡ | 40000 dots/㎡ | 15625 dots/㎡ | 10000 dots/㎡ |
| LED type | SMD1921 | SMD1921 | SMD3535 | SMD3535 |
| Cabinet size | 960×960×mm | 960×960×mm | 960×960×mm | 960×960×mm |
| Cabinet resolution | 240×240 | 192×192 | 120×120 | 96×96 |
| Cabinet material | Die casting aluminum | Die casting aluminum | Die casting aluminum | Die casting aluminum |
| Maintenance way | Rear | Rear | Rear | Rear |
| Best viewing distance | ≥4m | ≥5m | ≥8m | ≥10m |
| Best viewing angle | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° |
| Driving method (Constant Current) | 1/10Scan | 1/8 Scan | 1/5 Scan, | 1/2 Scan |
| Video frame rate | ≥60 Hz | ≥60 Hz | ≥60 Hz | ≥60 Hz |
| Refresh rate | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz |
| Brightness | ≥5500nits | ≥5500nits | ≥6000nits | ≥6000nits |
| Grey Level | 12-16bit | 12-16bit | 12-16bit | 12-16bit |
| Ingress protection | IP65 | IP65 | IP65 | IP65 |
| Life Time | >100,000 Hours | >100,000 Hours | >100,000 Hours | >100,000 Hours |
| The rate | <0.0002 | <0.0002 | <0.0002 | <0.0002 |
Features of Outdoor Fixed LED Display series
1. High brightness(≥6000nits), IP65 grade, adapt to outdoor enviroment.
2. High refresh rate(1920-3840Hz) and 12-16 bit Grey level make picture&video vivid.
3. Long life time(100000 hours) and low defective rate(<0.0002).
4. We have experienced engineer&sales team to provide professional service.
5. We are a 14 years leading LED display manufacturer, can provide most competetive factory price.
Applications:
Shopping malls, Bus station, Subway, Hospital, School, Large sports playground, Baseball field etc. With high brigthness and great protection from dust and moisture, they are used at outdoor places quite a lot and keep working for a long time.
After-sell Service:
1. 24-hour hotline service, including counseling and technical guidance.
2. 2 years warranty service.
3. Provide remote control debuggine serice for free if it's necessary for you.
4. Engineering technical service.
FAQ:
1.How about the delivery time?
About 22-24 days on average after we receiving the deposit.
2. Are you trading company or manufacturer?
We are a 14 years leading factory, specialzied in led screen industry.
3. What is the control system?
Novastar/LINSN/Colorlight for synchronous system, Novastar/Huidu for asynchronous system. we have several options for customer.
4. Can your factory accept OEM or ODM?
Yes,both OEM and ODM is OK.
5. What about the package and shipping way?
most situation packed with woden case and flight case,it's up to customers; delivered by air shipping or sea shipping.
