| Place of Origin: | Shenzhen, China |
| Brand Name: | KAILITE |
| Certification: | IOS9001 , IOS2000,FCC,RoHS,CE,CCC |
| Model Number: | P4,P5, P8, P10 |
| Minimum Order Quantity: | 2 square meters |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Wooden case |
| Delivery Time: | 22-24 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 8000 square meters per month |
| Pixel Pitch: | 5mm 8mm 10mm | Module Size: | 320*160mm |
|---|---|---|---|
| LED Type: | SMD3535 SMD1921 | Cabinet Size: | 960*960mm |
| Cabinet Material: | Iron | Video Frame Rate : | ≥60 Hz |
| The Rate: | <0.0002 | Color: | Full Color |
| High Light: | IP65 Led Display Full Color,SMD3535 Led Display Full Color,Full Color HD Led Video Wall |
||
Outdoor IP65 Led Display Full Color HD Video Wall Advertisement Board
Led Display Full Color Outdoor P5 P8 P10 IP65 HD Led Video Display
Description of outdoor led advertisement board
Outdoor fixed installation led screen designed for easy installation, and can be mounted on a variety of surfaces. including buildings, billboards, and even on the side of a turck. the displays can be customized to meet the specific needs of your project.
Specifications of outdoor led advertisement board
| Item | P5 | P8 | P10 |
| Pixel pitch | 5mm | 8mm | 10mm |
| Module size | 320*160mm | 320*160mm | 320*160mm |
| Module resolution | 64×32 | 40×20 | 32×16 |
| Physical density | 40000 dots/㎡ | 15625 dots/㎡ | 10000 dots/㎡ |
| LED type | SMD1921 | SMD3535 | SMD3535 |
| Cabinet size | 960×960×mm | 960×960×mm | 960×960×mm |
| Cabinet resolution | 192×192 | 120×120 | 96×96 |
| Cabinet material | Die casting aluminum | Die casting aluminum | Die casting aluminum |
| Maintenance way | Rear | Rear | Rear |
| Best viewing distance | ≥5m | ≥8m | ≥10m |
| Best viewing angle | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° |
| Driving method (Constant Current) | 1/8 Scan | 1/5 Scan, | 1/2 Scan |
| Video frame rate | ≥60 Hz | ≥60 Hz | ≥60 Hz |
| Refresh rate | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz |
| Brightness | ≥5500nits | ≥6000nits | ≥6000nits |
| Grey Level | 12-16bit | 12-16bit | 12-16bit |
| Ingress protection | IP65 | IP65 | IP65 |
| Life Time | >100,000 Hours | >100,000 Hours | >100,000 Hours |
| The rate | <0.0002 | <0.0002 | <0.0002 |
Features of outdoor led advertisement board
1. High brightness,more than 5500nits. It can even be seen under strong sunlight.
2. The visual distance is far, which is suitable for very high floors. It can also save space.
3. Easy and fast maintenance, rear service.
4. It amostly all formats videos and images.
Application of outdoor led advertisement board
Mainly used in outdoor advertising media, government and enterprise engineering, cultural tourism, sports venues, image publicity, commercial real estate and other fields.
Why choose KAILITE?
1. We can provide technician guides for you, if you don't how to installation an led screen. This free.
2. we insist quality frist.We will check the quality of products in every link of production.
3. More realiable: We have factory in Shenzhen, any time you can to visit our factory.
4. Cost-effective .We will provide you factory direct price.
After-sell Service:
1) A two-year warranty.
2) Under normal use, we will be responsible for any damage.
3) good service, if there any issues with our products, we will take our reponsibility.
FAQ:
1.Q: How much the shipping cost will take?
It depends on your other and your country. tell me your quantity, i will ask the freight forwarder.
2.Q: What is the warranty of your led display?
A: 2 years for all parts of led screen.
3:Q: What is your payment terms?
EXW, 40% in advance, 60% before shipment.
4. Can place an sample other?
Yes, sure.
5. What's the lead time for mass order?
Normally, it takes about 20-35 days, depends on the order quantity.
