Lightweight High Definition P5 Outdoor Full Color Led Display Boards , LED Video Screen

Lightweight High Definition P5 Outdoor Full Color Led Display Boards , LED Video Screen

  • Lightweight High Definition P5 Outdoor Full Color Led Display Boards , LED Video Screen
  • Lightweight High Definition P5 Outdoor Full Color Led Display Boards , LED Video Screen
Lightweight High Definition P5 Outdoor Full Color Led Display Boards , LED Video Screen
Product Details:
Place of Origin: Shenzhen, China(mainland)
Brand Name: OEM/ODM
Certification: CE,FCC,ROHS ISO9001
Model Number: P5
Payment & Shipping Terms:
Minimum Order Quantity: 2 suqare meter
Price: Negotiation
Packaging Details: wooden case/ flight case packing
Delivery Time: 5--20 working days
Payment Terms: T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability: 8000sqm per month
Contact Now
Detailed Product Description
Product Name: P5 Led Display Pixel Pitch: 5mm
Module Size(W * H): 160mm*160mm Tube Chip Color: Full Color
Resolution(W*H): 32dots*32dots Waterproof: IP65
High Light:

outdoor screen panels

,

outdoor led screen

Lightweight High Definition P5 Outdoor Full Color Led Display Boards , LED Video Screen



Product features



  • Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
  • Nice appearance and simple structures.
  • Jointed correctly, being installed & dismounted by one person without tool.
  • Humanized operating interface with breakdown indicator lights, easy to maintain.
  • High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.

Product details



Resolution/mm 5
Pixel configuration 1R1G1B
Pixel density/pixels/m² 40000/m²
Module resolution 32x32
Module size/mm 160x160
View distance 3-150m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 7000 cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >10000hours
Life time 100000hours
Life-all-white(brightness halving) 100000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <700W
Average power:/㎡ <500W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Our Services



  • Reply your enquiry in 24 working hours.



  • Experienced staffes answer all your questiones in fluent English.



  •  Customized desigh is avialiable OEM&ODM are welcomed.



  •  Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.



  • Special discount and protection of sales area provided to our distributor.





Excellent after-sale service

  • Warranty will be valid for 12 months against manufacturing defect.
  • The warranty shall not apply to the following circumstances:



1)  Damage caused by undue ware& tear, misuse, improper installation or operation, neglect, accidents.

2)  Damage caused by natural disasters, flood fire, lightning or pollution.
3)  If item was opened, any parts removed or repaired by any unauthorized person.





Why choose us



  • Continues Quality



With more than 9 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



  • Competitive Price



With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



  • Fast Delivery



Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



  • Perfect Service



Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.





FAQ



What about your Led Display quality ?



Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-10 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 9 years.Mass and professional production ensure

our led display’s competitiveness.





Packaging and shipping



A. Flight case Packing
1) 150KG Per flight case
2)  3 cabinets in one case
3)  Flight case size: 1010mm*560mm*1175mm=39inch*22inch*46inch



B. Plywood case
1) 180KG per plywood case
2)  3 cabinets in one case
3)  Plywood case size: 1120mm*585mm*930mm= 44inch*23inch*36inch



C.customized packing is acceptable
