| Place of Origin: | china |
| Brand Name: | kailite |
| Certification: | ccc ce rohs ul |
| Model Number: | p4 |
| Minimum Order Quantity: | 10sqm |
|---|---|
| Price: | US $110-910 / Square Meter |
| Packaging Details: | woodenbox |
| Delivery Time: | 15~20work days |
| Supply Ability: | 10000sqm/month |
| Module Size: | 256*128mm | Pixel Pitch: | 4mm |
|---|---|---|---|
| Pixel Density: | 62500 Dots/㎡ | Cabinet Reslution: | 128*128 |
| Drive Type: | Constant Drive | Brightness: | 1200cd/㎡ |
| Cabinet Size: | 512*512mm | Max Power: | 18W |
| Refresh Frequency: | ≥ 1920HZ/s | Relative Humidity: | 10%~90% |
| High Light: | led wall panel,large led display |
||
Smd led display wall indoor P4 rental led display advertising P4 High refresh indoor full color rental LED display
Quick Detail
1. Full color smd led screen without cover(Simple cabinet)
2. Module size 128*128mm
3. Generally it's use the wooden case to package
Applications
P4 indoor led displays are mainly used in shopping malls, hospitals, banks, enterprises and institutions, exhibition hall, sports venues, ticketing hall, hotels, securities companies, shopping malls, businesses, schools, arena, bank , securities, public security, transport, industry and commerce, electricity, customs, hospitals, parks, airports, railway stations, security, television and other fields.
Specifications
| Pixel Pitch | 4mm |
| Working Voltage | AC220V±10%; AC110V±10% |
| Power Consumption | Max 1000W/sqm Average 300W/sqm |
| LED Brand | Epistar LED Chips |
| Maximum Brightness | > 1400 cd/m² |
| Pixel Configuration | 1R1G1B |
| Pixel Size | 2121 |
| Pixel Density | 62500 Pixels/m² |
| Drive Mode | 1/16 Scanning |
| Grade Level | RGB 4096 grade/each |
| Best Viewing Distance | <4m ~ >150m (13ft ~ >492ft) |
| Viewing Angle | Horizontally >160° / Vertically >160° |
| Screen Lifetime | ≥ 100,000 hours |
| Driving IC | MBI |
| Refresh Frequency | ≥ 1920HZ/s (1,920+ HZ/s available) |
| Change Frame Frequency | ≥ 60Hz |
| Protection Level | IP31 |
| Control System | Simple LED Video Control System with Nova/Linsn or Advanced LED Video Processor |
| Ambient Temperature | -10°C ~ +45°C (-14°F ~ 113°F) |
| Relative Humidity | 10%~90% |
| Screen Weight | Steel: ≤ 18Kg/cabinet (40 Lbs) Aluminum: ≤ 15Kg/cabinet (33 Lbs) |
| Input Signal | RF S-Video RGB RGBHV YUVYC, etc. |
| Brightness Adjustment ² | 256 levels of each color (RGB) can be adjusted manually and 8 levels of each color can be adjusted automatically. |
| LED Module Size | 256mm x 128mm (7.6″ X 7.6″) (64 pixels x 32 pixels) |
| LED Cabinet Size | 512mm X 512mm (128 pixels x 128 pixels) |
| Cabinet Material | Steel or Aluminum or Die-casting Aluminum |
| Package Material | Wooden Case or flight case |
| Warranty | 2 Years |
Features
----- SMD: p2.5 p3 p4 p5 p6 p7.62 p10 indoor full color led module and led display.
----- all of our led module has highly resolution, good image effect,and easy to install and convenient to carry;
----- Resonable price, good uniformity, stable capability and high brightness;
----- Aluminum alloy material both for fixed installation and hanging rental;
----- Own Unique Design LED Screen
1. Your inquiry about our products or the price will be replied within 24 hours!
2. We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.
3. We will delivery goods as you demand ,you can choose the cheaper and more convenient way!
4. Apart from the Outdoor LED Display, Visionled also can offer you LED Pharmacy Cross Display, LED Flexible Display, Indoor LED Display, Indoor/outdoor LED Signs.
