1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens

1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens

1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens
1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens
1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens
Product Details:
Place of Origin: Guangdong,China
Brand Name: Kailite
Certification: CE FCC ROHS
Model Number: P4 outdoor
Payment & Shipping Terms:
Minimum Order Quantity: 2 square meters
Price: Negotiation
Packaging Details: Flight package and wood package
Delivery Time: ahout 20 days
Payment Terms: L/C, T/T
Supply Ability: 1500 SQM/per mouth
Contact Now
Detailed Product Description
Item: P4 Color: Full-color Real Pixels
Use Environment: Outdoor Pixel Pitch: 4mm
Module Size: 256*128mm Physical Density: 62500dots/㎡
Pixel Configuration: 1R1G1B LED Chip: SMD2525
Module Resolution: 64*32 Module Power: 20w
Recommended Viewing Distance: 4-28m Best Viewing Angle: H: 120°; V:120°
Maximum Power Consumption: 860w Video Frame Rate: ≥60 Hz
Cabinet Size: W768×H768mm Standard Cabinet Resolution: 192*192
High Light:

860w Outdoor Led Advertising Screens


SMD2525 Outdoor Led Advertising Screens


1R1G1B Outdoor Led Video Wall

P4 large outdoor led display screens led outdoor advertising screens outdoor led video wall



For Events, Wedding Ceremony, TV Stations, Contest - TV Station, Contest, - School, TV Shows, Exhibitions, Indoor and outdoor architectures, Commercial Marketing Performances, Public Square etc. They can replace any posters and static billboards and display any animation, video, or text with sound, and supply different experience and effect for clients’ advertisements.


Competitive advantages:

1. We are led screen manufacturer for many years, quality is guaranteed.
2. Because we are factory, our price is 5%-10% lower than middleman and trafficker at same level.
3. Professional sales and technical team of 15 people to ensure perfect results.
4. Customer requirements are fundamental, we make different solutions accroding different requirements of customers.


Item P4
Color Full-color real pixels
Use environment outdoor
Pixel pitch 4mm
Module size 256*128mm
Physical density 62500 dots/㎡
Pixel configuration 1R1G1B
LED chip SMD2121
Module resolution 64*32
Module power 20w
Recommended viewing distance 4-28m
Best viewing angle H: 120°; V:120°
Maximum power consumption 860w
Cabinet size W768m×H768mm
Standard cabinet resolution 192*192
Driving method 1/16 Scan, Constant Current
Video frame rate ≥60 Hz
Rate refresh ≥1200Hz
White balance brightness ≥1200cd
Operating temperature/Humidity -30℃~+45℃
Ingress protection IP43
Input voltage 110-220V AC±10%
Gray scale /Color Display Colors ≥16.7M(Synchronize)
Brightness control Manual/Automatic
Control system PCTV+DVI video card+control card+fiber
MBTF >5000 hours
Life Time >100,000 Hours
The rate <0.0001

  1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens 0

1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens 1

1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens 2

1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens 3





1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens 4

1R1G1B P4 SMD2525 860w Outdoor Led Advertising Screens 5


After-sale service

We promise we provide 2 years warranty for free maintain for our products and full life tracking service.

1. During the warranty period, we will repair the equipment free of charge unconditionally if the problem is caused by product quality or production and installation problem.

2. When the warranty expires. we continue to provide maintenance service for whole life of the equipment with relative service/material cost paid.


LED display screen: are widely used in Airports, stations, ports, stock exchange halls, financial institutions, sports venues, exhibitions, shopping centers, command and control centers, advertising media, etc.
Expect: We would like to express our desire to establish relationship with you on the basis of quality and mutually benefit.
Company​: Founded in 2009 which is a professional led display screen manufacturer in production, R&D and sales.
Products and advantages: Series full-color LED display products for Indoor/Outdoor/Rental retail, Rental, Advertising, Sports and the Corporate sector, Pixel pitch from P1.2 to P10. Products have passed the relevant certification and sold to all over the world with outstanding quality and price advantage.

We are the China Base LED Displays or Billboards Manufacturer. We providing our customers with the most complete LED product line and the most up-to-date LED sign solutions in the Digital Sign industry.
If you Interested in Our Services Visit www.rgbledscreen.com / request-a-quote/ for details.
