P2 Indoor Full Color Led Display Die Casting Aluminum 640*480mm

P2 Indoor Full Color Led Display Die Casting Aluminum 640*480mm

P2 Indoor Full Color Led Display Die Casting Aluminum 640*480mm
P2 Indoor Full Color Led Display Die Casting Aluminum 640*480mm
P2 Indoor Full Color Led Display Die Casting Aluminum 640*480mm
Product Details:
Place of Origin: Shenzhen, China
Brand Name: KAILITE
Certification: IOS9001 , IOS2000,FCC,RoHS,CE,CCC
Model Number: P2 P2.5 P3.07 P4
Payment & Shipping Terms:
Minimum Order Quantity: 2 square meters
Price: Negotiation
Packaging Details: wooden case&flight case
Delivery Time: 22-24 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 9000 square meters per month
Contact Now
Detailed Product Description
Color: 1R1G1B Led Lamp: SMD2020
Cabinet Material: Die-casting Aluminum Module Size: 320*160mm
Cabinet Size: 640*480mm IP: 43
Maintain Methods: Front Usage: Meeting
High Light:

IP43 P2 Indoor Full Color Led Display

,

1R1G1B Indoor Full Color Led Display

,

IP43 P2 Full Color LED Screen

IP43 P2 Indoor Full Color Led Display Die Casting Aluminun 640*480mm



Wall Mounted Led Screen Die-casting Aluminun 640*480mm IP43 Full Color Screen P2 Front Service Led Display


Quick details of indoor fixed led screen

1. Cabinet size with 640*480*59mm

2. LED lamp SMD1515/SMD2020

3. Ingress protection 43


4. Video frame rate:60Hz



Specifications of indoor fixed led screen

Item P2 P3.07 P4
Pixel pitch 2mm 3.076mm 4mm
Module size 320*160mm 320*160mm 320*160mm
Module resolution 160×80 104×52 80×40
Physical density 250000 dots/㎡ 105688 dots/㎡ 62500 dots/㎡
LED type SMD1515 SMD2020 SMD2020
Cabinet size 640*480*59mm 640*480*59mm 640*480*59mm
Cabinet resolution 320*240 208*156 160*120
Cabinet material Die casting aluminum Die casting aluminum Die casting aluminum
Maintenance way Front Front Front
Best viewing distance ≥2.5m ≥3m ≥3m
Best viewing angle H: 160°; V:160° H: 160°; V:160° H: 160°; V:160°
Driving method (Constant Current) 1/40 Scan 1/26 Scan, 1/20 Scan
Video frame rate ≥60 Hz ≥60 Hz ≥60 Hz
Refresh rate 1920-3840Hz 1920-3840Hz 1920-3840Hz
Brightness ≥800nits ≥800nits ≥800nits
Grey Level 12-16bit 12-16bit 12-16bit
Ingress protection IP43 IP43 IP43
Life Time >100,000 Hours >100,000 Hours >100,000 Hours
The rate <0.0002 <0.0002 <0.0002




Features of indoor fixed led screen
1. High color saturation, can show more uniform colors.

2. Ultra high definition with>3840Hz high refresh rate

3. Adopt mask design to protect dust and anti-collision

4. Easy and fast install

P2 Indoor Full Color Led Display Die Casting Aluminum 640*480mm 0
P2 Indoor Full Color Led Display Die Casting Aluminum 640*480mm 1P2 Indoor Full Color Led Display Die Casting Aluminum 640*480mm 2



Application of indoor fixed led screen
Stage performance, bar entertainment, ceremonial wedding,conference, exhibition,musical theater.




Why choose KAILITE?
1. We are a 14 years leading manufacturer specialized in led display industry.

2. Competitive price.We are the original manufacturer, no middleman make the difference.

3. High quality. Same product, Same price, Better quality.

4. Good service.We will try our best to serve you,we are standing by here to work for you at 7*24 hours.



After-sell Service:
1) Ultra long warranty period can be reached 2 years.

2) Providing customer with the loading program, so they can use as soon as they install the
led screen,don't need to debug again

3) We always be in here 7*24 hours. We will responed you any time.

4) Free technical training for how to use and handle the software.



FAQ:
1.Q: Do you support customized?
Yes. we support OEM/ODM services.

2.Q: How long will it take to receive the goods?
About 22-24 days.


3.Q: When can I arrange the production of my product?
As soon as the the deposit is paid, we will arrange production.
