High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance

High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance

  • High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance
  • High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance
  • High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance
  • High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance
High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance
Product Details:
Place of Origin: Shenzhen China
Brand Name: KAILITE
Certification: CE RoHS ISO9001 UL FCC CCC
Model Number: P3.07
Payment & Shipping Terms:
Minimum Order Quantity: 2 square meters
Price: Negotiation
Packaging Details: Wooden case/Flight case
Delivery Time: About 22-24 days
Payment Terms: T/T, L/C, D/A, D/P, MoneyGram, Western Union
Supply Ability: 8000 square meters per month
Contact Now
Detailed Product Description
Product Name: Front Maintenance P3.07 Indoor Fixed LED Display Pixel Pitch: 3.076mm
Module Size: 320*160mm Module Resolution: 104*52
Cabinet Size: 640*480mm Cabinet Resolution: 208*156
Cabinet Material: Iron/die-casting Aluminum Led Type: SMD2020
Refresh Rate: 1920-3840Hz Warranty: 2 Years
High Light:

3840Hz Indoor Fixed LED Display

,

3.076mm Indoor Fixed LED Display

,

3840Hz Led Display Full Color

High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance



Front Maintenance High Refresh Rate Customized P2 P2.5 P3.07 P4 Indoor Fixed LED Display



Features of products:


1. Front maintenance design, save space for maintenance.


2. High refresh rate and high resolution, better visual effects.


3. Customized shape and size, could make most suitable proposal.


4. Use brand LED lamp such as Nationstar and Novastar systerm, quality Is guanranteed.


5. Worry-free Service (Save your time and easy of your mind) from experienced engineers and sales team.



Product Specification:


Item KP2 KP2.5 KP3.07 KP4
Pixel pitch 2mm 2.5mm 3.076mm 4mm
Module size 320*160mm 320*160mm 320*160mm 320*160mm
Module resolution 160×80 128×64 104×52 80×40
Physical density 250000 dots/㎡ 160000 dots/㎡ 105688 dots/㎡ 62500 dots/㎡
LED type SMD1515 SMD2020 SMD2020 SMD2020
Cabinet size 640*480mm 640*480mm 640*480mm 640*480mm
Cabinet resolution 320*240 256*192 208*156 160*120
Maintenance way Front Front Front Front
Best viewing distance ≥2.5m ≥2.9m ≥3m ≥3m
Best viewing angle H: 160°; V:160° H: 160°; V:160° H: 160°; V:160° H: 160°; V:160°
Driving method (Constant Current) 1/40 Scan 1/32 Scan 1/26 Scan, 1/20 Scan
Video frame rate ≥60 Hz ≥60 Hz ≥60 Hz ≥60 Hz
Refresh rate 1920-3840Hz 1920-3840Hz 1920-3840Hz 1920-3840Hz
Brightness ≥800nits ≥800nits ≥800nits ≥800nits
Grey Level 12-16bit 12-16bit 12-16bit 12-16bit
Ingress protection IP43 IP43 IP43 IP43
Life Time >100,000 Hours >100,000 Hours >100,000 Hours >100,000 Hours
The rate <0.0002 <0.0002 <0.0002 <0.0002



High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance 0




Shipping and Package



The main shipping way is by sea and air, conbined with road transport. we have different choices for package, including Wooden case (most time for fixed series), flight case and cartoon.



High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance 1

High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance 2



After-sell service:


1. 24-hour hotline service, including counseling and technical guidance.


2. On-line service.


3. Failure maintenance of LED panels.


4. Free professional technical training.


5. Warranty service.



FAQ:


1. What is the delivery time?
About 22-24 days after we receiving the deposit.


2.Could i have a sample before place mass order?
Yes sure, sample is available for your test.


3. Are you factory?
yes we are 14 years leading factory, specialzied in led screen industry.


4. Is it okay to print my logo on your product?
Yes that's okay for us, we provide free printing service.


5. What is your terms of payment?
T/T 40% as deposit, and 60% before delivery. We'll show you the photos of the products and packages before you pay the balance.
